Abstract

Numerical analysis was performed to investigate the characteristics of the laminar fluid flow around an array of 3 D protruding heaters mounted on the bottom substrate of a parallel plane channel using the ANSYS/Fluent® 14.0 commercial software. The fluid flow was considered to have constant properties under steady state conditions. In the channel inlet, the velocity profile was uniform. This problem is associated with forced flow over the electronic components mounted on printed circuit boards. The conservation equations and their boundary conditions were numerically solved in a single domain through a coupled procedure. The discretization of the equations was based on the Control Volumes Method. The algorithm SIMPLE was used to solve the pressurevelocity couple. Due to the non-linearity of the momentum equation, the correction of the velocity components and the pressure were under-relaxed to prevent instability and divergence. After a study of the computational mesh independence, the numerical results were obtained, displayed as a 3 D non-uniform mesh with 212,670 control volumes. This computational mesh was more concentrated near the solid-fluid interface regions due to the larger primitive variable gradients in these regions. An investigation was done on the effects of the Reynolds numbers where the Reynolds numbers ranged from 100 to 300 and was dependent on the heights of the protruding heaters. The main characteristics of the fluid flow consisted of a small recirculation upstream of the heaters, the formation of horseshoe vortices around the protruding heaters’ side walls and a large recirculation region downstream of the heaters. The fluid dynamics parameters of interest, the velocity profiles, local and average skin friction coefficient, pressure distribution and the Darcy-Weisbach friction factor, were found and compared to the results available in the literature.

References

15 Cites in Article
  1. 1. J. Hwang,K. Yang (2004). Numerical study of vortical structures around a wall-mounted cubic obstacle in channel flow. pp, 16, 402-020.
  2. 2. A. Van Dijk,H. De Lange (2007). Compressible laminar flow around a wall-mounted cubic obstacle. Computers & Fluids, 36(5), 949-960.
  3. 3. I. Castro,A. Robins (1977). The flow around a surface-mounted cube in uniform and turbulent streams. Journal of Fluid Mechanics, 79(2), 307-335.
  4. 4. R. Martinuzzi,C. Tropea (1993). The Flow Around Surface-Mounted, Prismatic Obstacles Placed in a Fully Developed Channel Flow (Data Bank Contribution). Journal of Fluids Engineering, 115(1), 85-92.
  5. 5. C. Tropea,R. Gackstatter (1985). The Flow Over Two-Dimensional Surface-Mounted Obstacles at Low Reynolds Numbers. Journal of Fluids Engineering, 107(4), 489-494.
  6. 6. S. Okamoto,T. Katsumata,N. Abe,M. Kijima (1997). Flow Past Repeated Ribs of a Square Section Mounted on a Ground Plane. Trans. Jpn. Soc. Mech. Eng, 63, 3834-3842.
  7. 7. T. Alves (2010). Resfriamento conjugado de aquecedoresdiscretosemcanais. Tese (Doutoradoem EngenhariaMecânica) - Faculdade de EngenhariaMecânica.
  8. 8. T. Altemani (2012). An invariant descriptor for heaters temperature prediction in conjugate cooling. Int. J. Thr. Sci, 58, 92-101.
  9. 9. J. Davalath,Y. Bayazitoglu (1987). Forced Convection Cooling Across Rectangular Blocks. Journal of Heat Transfer, 109(2), 321-328.
  10. 10. Yong Zeng,Kambiz Vafai (2009). An Investigation of Convective Cooling of an Array of Channel-Mounted Obstacles. Numerical Heat Transfer, Part A: Applications, 55(11), 967-982.
  11. 11. S. Patankar (1980). Numerical heat transfer and fluid flow.
  12. 12. A. Bar-Cohen,A. Watwe&,R. Prasher (2003). Heat transfer in electronic equipment. Heat transfer handbook, 13, 947-1027.
  13. 13. F. Incropera,D. Dewitt,T. Bergman,A. Lavine (2008). Fundamentos de transferência de calor e de massa. LivrosTécnicos e Científicos Editora.
  14. 14. Garron Morris,Suresh Garimella (1996). Thermal wake downstream of a three-dimensional obstacle. Experimental Thermal and Fluid Science, 12(1), 65-74.
  15. 15. F. Nishida Análisenumérica do escoamento laminar e da transferência de calor de aquecedores.

Funding

No external funding was declared for this work.

Conflict of Interest

The authors declare no conflict of interest.

Ethical Approval

No ethics committee approval was required for this article type.

Data Availability

Not applicable for this article.

How to Cite This Article

Thiago Antonini Alves, Felipe Baptista Nishida. 2014. "Laminar Flow around an Array of 3D Protruding Heaters Mounted in Cross-Stream Direction". Global Journal of Research in Engineering - A : Mechanical & Mechanics GJRE-A Volume 13 (GJRE Volume 13 Issue 41 (A10)).
