Abstract

The satellite launch vehicle currently developed in Brazil, need that their modules are integrated into an unit called by Integration Movable Tower. In the tower structure is installed: moving bridge, elevator, work platforms, doors, movement trucks and other equipment that aids the accomplishment of integration tasks, tests and vehicle launching. In order to perform the foreseen procedures in the aforementioned tasks, the equipment are submitted to several operational tests prior to utilization of integration tower control system. On that context, this work presents a proposal of model developed by means of Petri Nets to represent the algorithm steps that tests the sensors and actuators included into the main equipment installed in the mentioned integration tower. That is carried out computational simulations with the target of identifying the Petri Nets properties that are related to the confusion conflicts and dead lock. The results obtained in the simulations indicates that the proposed model is able of representing the sensors and actuator operation embedded inside a standard equipment during the self test and based upon that is evaluated the algorithm performance.

References

9 Cites in Article

Reference Format

A Palmerio (2002). Introducao a Engenharia de Foguetes.
F Yamanaka (2006). Analise de Faltas em Modelo Representativo de Sistema Eletrico Proposto para Plataforma de Lancamento de Veiculos Espaciais.
Aline Silva,Osania Ferreira,Gustavo Costa,Nayara Montijo,Miguel Mutton,Márcia Mutton (2005). Technological quality of sweet sorghum processed without panicles for ethanol production.
P Miyagi (1996). Controle Programavel -Fundamentos do Controle de Sistemas a Eventos Discretos.
P Silveira (2002). Automacao e Controle Discreto, 4a Edicao -Erica.
Raquel De Barros Pinto Miguel,Djenifer Marx,Gilmara Arndt (1997). Surfando na onda digital: Feminismos em rede no Brasil.
Renata Da Costa,Emiliane Pereira,Fabricio Silva,Edgar De Jesus,Fernando Souza Jr. (2001). Drug Micro-Carriers Based on Polymers and Their Sterilization.
R Petterle (2009). Redes de Petri Aplicadas na Analise de Algoritmo para Autoteste de Torre De Integracao de Veiculos Espaciais.
Robert Anholt (2006). Visual Displays.

Download References

Funding

No external funding was declared for this work.

Conflict of Interest

The authors declare no conflict of interest.

Ethical Approval

No ethics committee approval was required for this article type.

Data Availability

Not applicable for this article.

How to Cite This Article

Francisco Carlos Parquet Bizarria, Jose Walter Parquet Bizarria, Joao Mauricio Rosario. 2011. "Petri Nets applied to the Analysis of Algorithm for Space Vehicles Integration Tower Self Test". Global Journal of Research in Engineering - D: Aerospace Science GJRE-D Volume 11 (GJRE Volume 11 Issue D5).
