Pneumococcal meningitis caused by Streptococcus pneumoniae strains has been reported as the third primary aetiology of bacterial meningitis in parts of Northern Nigeria. However, information on the genotypes of S. pneumoniae strains circulating in Northern Nigeria is unavailable in the literature. Genotyping is being practiced widely in medical microbiology and has been shown to be an invaluable tool in tracking strains responsible for disease outbreaks. We aimed at determining the genotypes of S. pneumoniae tracked to a pneumococcal meningitis outbreak in parts of Northern Nigeria. The multilocus sequence typing (MLST) scheme, a DNA sequencing based genotyping method of sequencing segments of seven internal housekeeping genes, was used. The PubMLST.org database and Bacterial Isolate Genome Sequence Database software was equally used.
## I. INTRODUCTION
The aetiologic agent of pneumococcal meningitis, Streptococcus pneumoniae has been reported as one of the most common causes of bacterial meningitis beyond the newborn period [CDC, 2011, Chap. 2]. In a very recent study by Peletiri and colleagues, S. pneumoniae was reported as the third primary aetiology of bacterial meningitis in parts of northern Nigeria. The authors reported encountering four serotypes of S. pneumoniae including serotype 1 (Wzy 1), serotype 4 (Wzy 4), serotype 5 (Wzy 5), and serotype 9 (Wzy 9) as the offending serotypes [Peletiri et al., 2021b]. Meanwhile, some authors had earlier reported serotypes 1, 5, and 19F [Kwambana-Adams et al., 2018] and serotypes 6, 19, and 20 [Suleiman et al., 2018] in Northern Nigeria. Information on the circulating genotypes of S. pneumoniae in Northern Nigeria is unavailable in the literature. Genotyping is also known as DNA fingerprinting [Wenjun et al., 2009].
The multilocus sequence typing (MLST) methodology is a DNA sequencing based genotyping method that generates the original sequence of nucleotides and discriminates among bacterial strains directly from polymorphisms in their DNA [Chan et al., 2001]. The MLST scheme indexes the sequence of seven internal housekeeping gene fragments to identify bacterial genotypes and associate them with biological properties [Chan et al., 2001; Jolley et al., 2004; Maiden et al., 1998]. MLST scheme is available for S. pneumoniae based on DNA sequencing of fragments of seven housekeeping loci (aroE, gdh, gki, recP, spi, xpt, and ddl) [Enright & Spratt, 1998]. The assignment of alleles at each locus is carried out using the MLST website (http://www.pubmlst.streptococcusneumoniae).
The American Society for Microbiology Journals (journals.asm.org/nomenclature) gave explicit instructions to authors on bacteria genetic nomenclature and genotype designations. The genetic properties of bacteria are described in terms of phenotypes and genotypes. The phenotype describes the observable properties of an organism. The genotype refers to the genetic constitution of an organism, with reference to some standard wild type. Genotype designations are indicated by three-letter locus symbols with lowercase italic (e.g., ara, his, rps). If several loci govern related functions, these are distinguished by italicized capital letters following the locus symbol (e.g., araA, araB, araC). We aimed at determining the genotypes of S. pneumoniae tracked to a pneumococcal meningitis outbreak in parts of Northern Nigeria.
## II. MATERIALS AND METHODS
### a) Ethics Approval and Consent to Participate
Ethical approval was obtained from the Health Research Ethics Committees of National Hospital, Abuja, Nigeria (NHA/EC/034/2015); Federal Capital Development Authority Health Services, Abuja, Nigeria
(FHREC/2017/01/27/03-04-17); Kebbi State Ministry of Health, Nigeria (MOH/KSREC/VOL.1/56/No101.3/2015); Plateauan State Ministry of Health, Nigeria (MOH/MIS/202/VOL.T/X, 2017); Sokoto State Ministry of Health, Nigeria (SMH/1580/V.IV, 2017), and Zamfara State Ministry of Health, Nigeria (ZSHREC/02/03/2017) [Peletiri et al., 2021a; 2021b]. Written informed consent for the storage and future use of the unused sample, and sample material and data transfer agreement were also obtained [Peletiri et al., 2021a; 2021b].
### b) Sample Size Determination
The sample size was calculated using the Cochran formula [Cochran, 1977] for calculating simple proportion. At 0.05 alpha level of significance, $95\%$ confidence level and patient population size of seventy-seven and a previous prevalence of $13.7\%$, a sample size of 181.7, which was adjusted to 210 samples after calculating $10\%$ attrition [Peletiri et al., 2021a; 2021b]. The subjects were recruited consecutively until the sample size was attained [Peletiri et al., 2021a; 2021b].
### c) Sample Collection
Cerebrospinal fluid samples collection was as previously reported [Peletiri et al. 2021a].
### d) Extraction and Quality Check of Metagenomic DNA
Metagenomic DNA extraction methodology and quality check methods were as reported previously [Peletiri et al., 2021a].
### e) Multiplex Real-Time PCR for S. pneumoniae Detection
Multiplex Real-time PCR protocol for molecular detection of S. pneumoniae was as previously reported [Peletiri et al., 2021b].
### f) Singleplex Real-time PCR for S. pneumoniae Characterization
Singleplex Real-time PCR protocol for molecular characterization of S. pneumoniae was as previously reported [Peletiri et al., 2021b].
### g) Sample Selection
Of the appropriately characterized 12 S. pneumoniae serotyped strains with singleplex Real- time PCR as reported by Peletiri et al., (2021b), eight $(66.7\%)$ were properly selected for genotyping to ensure both geographical coverage (spread) and serotype representation or distribution.
### h) Multilocus Sequence Typing (MLST) Protocol for S. pneumoniae Genotyping
The Real-time PCR method of Multilocus Sequence Typing (MLST) using SYBR chemistry, is designed to genotype selected genotypic markers of S. pneumoniae. The assay detects seven genotypic markers: aroE, gdh, gki, recP, spi, xpt, and ddl [Enright & Spratt, 1998; Maiden, 2000; Maiden et al., 1998], as in Table 1. The primers used for amplification by Real-time
PCR were: aroE-F (5'- GCCTTTGAGGCGACAGC-3'), and aroE-R (5'TGCAGTTCAGAAAACATATTTCTAA-3'); gdh-F (5'-ATGGACAAACCAGCNAGCTTT-3'), and gdh-R (5'-GCTTGAGGTCCCATGACTNCC-3'); gki-F (5'-GGCAATTGGAATGGGATCACC-3'), and gki-R (5'-TCTCCCGCAGCTGACAC-3'); recP-F (5'-GCCAACTCAGGTCATCC-AGG-3'), and recP-R (5'-TGCAA-CCGTAGCATTGTAAC-3'); spi-F (5'-TTATTCCTCCTGA-TTCTGTC-3'), and spi-R (5'-GTGATTGGCCA-GAAGCGGAA-3'); xpt-F (5'-TTATTA-1GAAGAGCG-CATCCT-3'), and xpt-R(5'-AGATCTGCC-TCCTT-AAATAC-3'); ddl-F (5'-TGCCTCAAGTTCCTTATGTGG-3'), and ddl-R (5'-CACTGGGTGAAAACCATGG-CAT-3').
All primers were synthesized by Eurofins, Germany. Primers were supplied lyophilized. Primers were first reconstituted to $100\mu \mathrm{M}$ (working stock) following the manufacturer's instructions and working concentrations of $10\mu \mathrm{M}$ prepared using DNA elution buffer (or TE buffer) as diluent.
### i) MLST Protocol Set-up
## i. Sample Requirement
Metagenomic DNA (mDNA) samples of serotyped S. pneumoniae with singleplex Real-time PCR, stored at $-20^{\circ}\mathrm{C}$ (or at $-80^{\circ}\mathrm{C}$ ) until required for testing.
### j) Reagents and Materials
10 μM S. pneumoniae primer mixes labelled aroE, gdh, gki, recP, spi, xpt, and ddI mix, respectively. qPCR Master Mix (SYBR); PCR water (Nuclease free water); ABI One Step Plus Real-time PCR System (Thermofisher, UK); ABI 96 well qPCR plate; P10, P100, and P1000 pipettes and tips; Thermal seal for PCR microtitre plate; Cold rack; Refrigerated centrifuge with plate holder (Heraeus, UK).
### k) Setting up Reaction
A worksheet was created according to the number of samples to be tested. The ABI 96 well plate was placed into a plate holder on a cold rack. Note: Each genotypic marker was tested at a time. So, for each sample, there were seven separate reactions. Into each well, $15~\mu \mathrm{L}$ of qPCR Master mix/Primer was dispensed. Five (5) $\mu \mathrm{L}$ of sample (mDNA), Positive control and Negative control (PCR water) was added into the appropriate well. The plate was sealed with a thermal seal and centrifuged at $1000~\mathrm{rpm}$ for 1 minute in a refrigerated centrifuge $(2 - 8^{\circ}\mathrm{C})$. The microtitre plate was placed into the holder in the ABI One Step Plus Real-time PCR machine. The manufacturer's instruction was followed in setting up the template -S. pneumoniae genotyping. To commence testing, SYBR Chemistry and Standard mode, with Absolute Quantification, were selected. The run was started and saved correctly. The thermal profile comprised of initial denaturation at $95^{\circ}\mathrm{C}$ for $3\mathrm{min}$, followed by 40 cycles of $95^{\circ}\mathrm{C}$ for $5\mathrm{s}$, $60^{\circ}\mathrm{C}$ for
30s, $72^{\circ}\mathrm{C}$ for 10s, and a final melt cycle of $72^{\circ}\mathrm{C}$ to $95^{\circ}\mathrm{C}$ at ramp rate of $0.3^{\circ}\mathrm{C} / \mathrm{s}$.
### i) Result Analysis
After the run, the amplification curve and cycle threshold (Ct) values were inspected. Ct values of $< 35$ were positive; Ct values of $35 - 40$ were equivocal; Ct values $>40$ were negative. For the equivocal ones, the amplification curve and melting curve should be checked to decide the result. If it melts at the same specific temperature as the positive cases, it should be considered positive.
### j) Sequenced Results from MLST
The genome sequences obtained from genotyping (MLST protocol) was uploaded to the publicly available Streptococcus PubMLST.org database(http://pubmlst.org/streptococcuspneumoniae) [Jolley & Maiden, 2014], powered by the Bacterial Isolate Genome Sequence Database (BIGSdb) software [Jolley & Maiden, 2010] for the determination of sequence type (ST), biotype, and global epidemiology status.
### k) Extracting Typing Information from a Local Genome File
The MLST scheme from a drop-down box of the PubMLST.org database for Streptococcus was selected, and the analysis run started by clicking the submit button. Individual allelic matches identified along with the sequence type (ST) if the combination of alleles has been previously defined [Jolley et al., 2018]. Typing information can be readily extracted from whole genome sequence assemblies using the sequence query pages. Genome assembly contids pasted into the sequence query form of the database, and the required scheme or locus was selected. Any locus exact matches are displayed, and, if this corresponds to a defined combination of alleles, the profile definition (Sequence type (ST) / clonal complex (cc) for MLST) was displayed [Jolley et al., 2018].
## III. RESULTS
Of the eight genotyped isolates with MLST, three (37.5%) had detectable genotypes, while five (62.5%) were undetectable genotype strains. Of the seven genotypes tested, we encountered only two genotypes: genotype aroE, two cases (25%) found circulating within serotype 4 (Wzy 4), and genotype gki in one case (12.5%) found circulating within serotype 5 (Wzy 5) (Table 2). For genotype aroE, one sequence type (ST) 12750 was identified, while for genotype gki, two sequence types (ST) 11337 and 13103 were identified (Table 3). Results for S. pneumoniae genotypes sequence profile extracted from PubMLST.org powered by BIGSdb software as shown in Tables 3 to 5.
## IV. DISCUSSION
Knowledge of the genetic diversity of pathogens is being exploited more directly in the study of epidemiology. In molecular epidemiology parlance, genetic diversity is commonly referred to as 'typing' or 'genotyping'. Genotyping is being practiced widely in medical microbiology and has shown to be an invaluable tool in tracking strains responsible for disease outbreaks; particularly useful in studying and controlling nosocomial outbreaks and to ascertain whether the relapse of an infectious disease after therapeutic intervention, was due to treatment failure or recolonization of the host by a new strain [Virdi & Sachdeva, 2005]. S. pneumoniae genome sequence on the PubMLST.org for typing by MLST allelic profile through a search by specific schemes such as Penicillin-binding proteins (PBPs) and Pneumococcal surface protein A (PspA), results were not available. However, under the PubMLST pneumococcal genome library page, we could extract the global epidemiology status.
Our query of genotype aroE by filtering on serotype 4 (Wzy 4) revealed varying sequence types (ST) and alleles. While isolates from The Netherlands had two STs (ST 247, allele 16 and ST 205, allele 10), those from South Africa had the same ST and allele (ST 1221, allele 7) [Gladstone et al., 2020]. Though they were silent in the genomic status of these isolates; our search from the PubMLST.org database confirmed that serotype 4 (Wzy 4) was also found in these countries (Table 4). Our query of genotype gki by filtering on serotype 5 (Wzy 5) displayed a single ST 5659 and allele number 16 from South Africa alone submitted between 2006 and 2012 (Table 5) [Gladstone et al., 2020].
## V. CONCLUSION
The MLST results provided an overview of circulating S. pneumoniae genotypes and their genetic diversity status, which is a piece of information for public health strategies such as vaccination. To develop more effective vaccines, it is imperative that the candidate vaccines must be evaluated against a set of carefully selected genotypes, which are representative of the pathogen population [Dykuizen et al., 1993]. The tracking of identified genotypes of S. pneumoniae (aroE and gki) to a pneumococcal meningitis outbreak in parts of Northern Nigeria is being reported as baseline data for reference.
ACKNOWLEDGEMENTS
We acknowledge the Federal Ministry of Health, Nigeria and the ethics committee members of National Hospital, Abuja, Nigeria; Kebbi State Ministry of Health, Nigeria; Plateau State Ministry of Health, Nigeria; Sokoto State Ministry of Health, Nigeria; and Zamfara State
Ministry of Health. All staff of the various medical laboratories where the samples were received and phenotypically processed are appreciated [Peletiri et al., 2021a, 2021b]. Also, we wish to appreciate the MD/CEO of Safety Molecular Pathology Laboratory (SMPL), Enugu, Enugu State, Nigeria, Dr. Emmanuel Nna (PhD) for training the principal investigator in the practical application of metagenomic protocol and general orientation in molecular diagnostic techniques in the PCR laboratory of his institute. Also appreciated are all staff of SMPL, Enugu for the various roles they played in the course of running of all samples for preparation of metagenomic DNA template and actual molecular diagnostic procedures. This research utilized the PubMLST database (https://pubmlst.org) developed by Keith Jolley [Jolley & Maiden, 2010]. Funding of this research was solely by the 'principal investigator' (corresponding author).
Table 1: S. pneumoniae MLST scheme, including gene locus, amplicon length, and trimmed length of sequence used for allelic determination on http://www.mlst.net platform (CDC, 2011, Chap. 12).
<table><tr><td>Housekeeping genes</td><td>Gene locus</td><td>Trimmed length</td></tr><tr><td>Shikimate dehydrogenase</td><td>aroE</td><td>405</td></tr><tr><td>Glucose-6-phosphate dehydrogenase</td><td>gdh</td><td>460</td></tr><tr><td>Glucose kinase</td><td>gki</td><td>483</td></tr><tr><td>Transketolase</td><td>recP</td><td>450</td></tr><tr><td>Signal peptidase I</td><td>spi</td><td>474</td></tr><tr><td>Xanthine phosphoribosyltransferase</td><td>xpt</td><td>486</td></tr><tr><td>D-alanine-D-alanine ligase</td><td>ddl</td><td>441</td></tr></table>
Table 2: Prevalence of circulating S. pneumoniae genotypes amongst the various identified serotypes in parts of Northern Nigeria
<table><tr><td>Gene locus</td><td>Allele</td><td>Number encountered</td><td>%</td><td>Circulating amongst serotype</td><td>Number of serotype</td></tr><tr><td>aroE</td><td>405</td><td>2</td><td>25.0</td><td>Wzy 4</td><td>1</td></tr><tr><td>gki</td><td>483</td><td>1</td><td>12.5</td><td>Wzy 5</td><td>1</td></tr><tr><td colspan="2">Undetectable genotype strains</td><td>5</td><td>62.5</td><td></td><td></td></tr><tr><td colspan="2">Total</td><td>8</td><td>100.0</td><td></td><td></td></tr></table>
Table 3: Genotypes of S. pneumoniae allelic profile for Sequence type (ST) and clonal complex (cc) extracted from PubMLST.org powered by BISGdb software
<table><tr><td rowspan="2">Gene Locus</td><td rowspan="2">Allele</td><td rowspan="2">Sequence Type (ST)</td><td rowspan="2">Clonal complex (cc)</td><td colspan="2">BURST analysis Singletons</td></tr><tr><td>ST</td><td>Frequency</td></tr><tr><td>aroE</td><td>405</td><td>12750</td><td>Nil</td><td>Nil</td><td></td></tr><tr><td>gki</td><td>483</td><td>11337</td><td>Nil</td><td>11337</td><td>1</td></tr><tr><td></td><td></td><td>13103</td><td>Nil</td><td>13103</td><td>1</td></tr></table>
Table 4: S. pneumoniae genotype aroE sequence profile extracted for Serotype 4 (Wzy 4) from PubMLST.org powered by BIGSdb for global epidemiology status
<table><tr><td>Id</td><td>Isolate</td><td>Country</td><td>Year</td><td>Serotype</td><td>MLST (aroE) Allele</td><td>ST</td></tr><tr><td>49181</td><td>AMCSP09</td><td>The Netherlands</td><td>2008</td><td>4</td><td>16</td><td>247</td></tr><tr><td>49190</td><td>AMCSP18</td><td>The Netherlands</td><td>2008</td><td>4</td><td>10</td><td>205</td></tr><tr><td>116970</td><td>GPS_ZA_3068</td><td>South Africa</td><td>2014</td><td>4</td><td>7</td><td>1221</td></tr><tr><td>117961</td><td>GPS_ZA_1432</td><td>South Africa</td><td>2008</td><td>4</td><td>7</td><td>1221</td></tr></table>
Table 5: S. pneumoniae genotype gki sequence profile extracted for Serotype 5 (Wzy 5) from PubMLST.org powered by BIGSdb for global epidemiology status
<table><tr><td>Id</td><td>Isolate</td><td>Country</td><td>Year</td><td>Serotype</td><td>MLST (gki) Allele</td><td>ST</td></tr><tr><td>117626</td><td>SA_GPS_SP259</td><td>South Africa</td><td>2012</td><td>5</td><td>16</td><td>5659</td></tr><tr><td>117672</td><td>SA_GPS_SP191</td><td>South Africa</td><td>2012</td><td>5</td><td>16</td><td>5659</td></tr><tr><td>117879</td><td>GPS_ZA_695</td><td>South Africa</td><td>2006</td><td>5</td><td>16</td><td>5659</td></tr><tr><td>117908</td><td>GPS_ZA_1145</td><td>South Africa</td><td>2010</td><td>5</td><td>16</td><td>5659</td></tr><tr><td>118148</td><td>GPS_ZA_1806</td><td>South Africa</td><td>2010</td><td>5</td><td>16</td><td>5659</td></tr><tr><td>118188</td><td>GPS_ZA_2259</td><td>South Africa</td><td>2011</td><td>5</td><td>16</td><td>5659</td></tr></table>
