Resonance Characteristics Enhancement of Slot-loaded Microstrip Patch Antenna for GPS Application

Rakib Hasan; Mustakim Ahmed Rahat; Sakhawat Hussain

Resonance Characteristics Enhancement of Slot-loaded Microstrip Patch Antenna for GPS Application

Rakib Hasan * §

Contact

Mustakim Ahmed Rahat

Contact

Sakhawat Hussain

Contact

University of Dhaka

Resonance Characteristics Enhancement of Slot-loaded Microstrip Patch Antenna for GPS Application

Article Fingerprint

ReserarchID

REW2TLV

Resonance Characteristics Enhancement of Slot-loaded Microstrip Patch Antenna for GPS Application Banner

AI TAKEAWAY

Connecting with the Eternal Ground

Abstract

For GPS application, a rectangular microstrip patch antenna has been designed and fabricated focusing on single resonant frequency at 1.575 GHz of the L-1 band. Slots are incorporated into the patch to fine-tune the resonant frequency, decrease the return loss, and increase the directivity and bandwidth. The proposed antenna has four rectangular slots of different sizes on the patch. The antenna is designed by commercially available simulation software. The simulation result shows that it resonates at 1.536 GHz with a return loss value of -50.72 dB having a bandwidth of 48.5 MHz and directivity of 7.13 dBi and the fabricated antenna has a resonant frequency of 1.5 GHz with return loss and bandwidth of -25 dB and 30 MHz, respectively. It is found that the proposed antenna perform much better than a conventional microstrip patch antenna.

Funding

No external funding was declared for this work.

Conflict of Interest

The authors declare no conflict of interest.

Ethical Approval

No ethics committee approval was required for this article type.

Data Availability

Not applicable for this article.

How to Cite This Article

Rakib Hasan, Mustakim Rahat, Sakhawat Hussain. 2018. "Resonance Characteristics Enhancement of Slot-loaded Microstrip Patch Antenna for GPS Application". Global Journal of Research in Engineering, Global Journal of Research in Engineering - F: Electrical & Electronic GJRE-F Volume 18 (GJRE Volume 18 Issue F1).
