## I. INTRODUCTION ### a) Structural Systems In the earliest structures at the beginning of the 20th century, structural members were assumed to carry primarily the gravity loads. Today, however, by the advances in structural design/systems and highstrength materials, building height is increased, which necessitates taking into consideration mainly the lateral loads such as wind and earthquake. Understandably, especially for the tall buildings, as the slenderness, and so the flexibility increases, buildings suffer from the lateral loads resulting from wind and earthquake more and more. As a general rule, when other things being equal, the taller the building, the more necessary it is to identify the proper structural system for resisting the lateral loads. Currently, there are many structural systems that can be used for the lateral resistance of tall buildings[2,3]. Structural systems of tall buildings can be divided into two broad categories: interior structures and exterior structures. This classification is based on the distribution of the components of the primary lateral load-resisting system over the building. ### b) Shear Wall Structure Shear Wall-Frame Systems (Dual Systems), The system consists of reinforced concrete frames interacting with reinforced concrete shear walls are adequate for resisting both the vertical and the horizontal loads acting on them. ### c) Necessity of Shear Walls Shear wall system has two distinct advantages over a frame system. - It provides adequate strength to resist large lateral loads with-out excessive additional cost. - It provides adequate stiffness to resist lateral displacements to permissible limits, thus reducing risk of non-structural damage. ### d) Seismic Load The seismic weight of building is the sum of seismic weight of all the floors [8]. The seismic weight of each floor is its full dead load plus appropriate amount of imposed load, the latter being that part of the imposed loads that may reasonably be expected to be attached to the structure at the time of earthquake shaking. Earthquake forces experienced by a building result from ground motions (accelerations) which are also fluctuating or dynamic in nature, in fact they reverse direction somewhat chaotically[2,3]. In theory and practice, the lateral force that a building experiences from an earthquake increases in direct proportion with the acceleration of ground motion at the building site and the mass of the building. As the ground accelerates back and forth during an earthquake it imparts back-and-forth (cyclic) forces to a building through its foundation which is forced to move with the ground [1]. ### e) Geo-Technical Consideration The seismic motion that reaches a structure on the surface of the earth is influenced by local soil conditions. The subsurface soil layers underlying the building foundation may amplify the response of the building to earthquake motions originating in the bedrock. Three soil types are considered here: I. Hard - Those soils, which have an allowable bearing capacity of more than $10\mathrm{t / m}2$ II. Medium - Those soils, which have an allowable bearing capacity less than or equal to $10\mathrm{t} / \mathrm{m}^2$ III. Soft - Those soils, which are liable to large differential settlement or liquefaction during an earthquake. The allowable bearing pressure shall be determined in accordance with IS: 1888-1982 load test (Revision 1992). ## II. METHODOLOGY a) To understand and evaluation building structures and aims to the effect of Seismic load on column Forces in Different Type of RC Shear Walls in Concrete Frame Structures under Different Type of Soil Condition with seismic loading. b) Modeling a $G + 29$ story high building for five different cases [9-11]. c) Analyzing the building dynamic analysis using linear, i.e. Response Spectrum Analysis [1-3]. d) Analyzing the results and arriving at conclusions. a) Dynamic Analysis - Dynamic analysis may be executed to get the design seismic force, and its spread in different levels through the height of the building, and also various lateral load resisting element[1-2-3,8]. b) Response Spectrum Method This method is executed to design spectrum, where as it is specified with a code for specific- site design can be used for a project site for the purposes of dynamic of steel and reinforce concrete buildings, the values of damping for building may be taken as 2 and 5 percent of the critical, respectively. response spectrum method is typically implemented in linear elastic procedures and also very much easier to use. This also called as or mode superposition method or model method, It also made on the idea of the superposition of responses given by the building through various modes of vibrations, each vibration modes is recorded as with its own particular deformed shape, with its own modal damping and its own frequency [7,8]. ## III. MODELING OF BUILDING ### a) Details of the Building A symmetrical building[15] of plan $38.5\mathrm{m}$ X $35.5\mathrm{m}$ located with location in high Seismic zone considered. Four bays of length $7.5\mathrm{m}$ & one bays of length $8.5\mathrm{m}$ along X - direction and four bays of length $7.5\mathrm{m}$ & one bays of length $5.5\mathrm{m}$ along Y - direction are provided. Shear is provided the center inner core of model building. Struct I: G+29 story'shall building with Plus shape RC shear wall at the center of structure. Struct II: G+29 story'stall building with Box shape RC shear wall at the center of structure. Struct III: G+29 story'stall building with C- shape RC shear wall at the center of structure. Struct IV: G+29 story'stall building with E- shape RC shear wall at the center of structure. Struct V: G+29 story'stall building with I- shape RC shear wall at the center of structure. ### b) Load Combinations As per IS 1893 (Part 1): 2002 Clause no. 6.3.1.2, the following load cases have to be considered for analysis: $$ \begin{array}{l} 1.2 (DL + IL \pm EL) ^ {\prime} \\1.5 (DL \pm EL) \\^ {\prime \prime} EQXP \& EQYP ^ {\prime \prime} \\\end{array} $$ Earthquake load must be considered for $+\mathrm{X}$, $-\mathrm{X}$, $+\mathrm{Y}$ and $-\mathrm{Y}$ Directions [5-7]. ### c) The Building Details Type of frame: Special RC moment resisting frame fixed at the base, Number of storeys: G+29, Floor height: 3.5 m, Depth of Slab: 225 mm, Size of beam: (300 × 600) mm, Size of column (exterior): (1250×1250) mm up to story five, Size of column (exterior): (900×900) mm Above story five, Size of column (interior): (1250×1250) mm up to story ten, Size of column (interior): (900×900) mm Above story ten, Live load on floor: 4 KN/m2, Floor finish: 2.5 KN/m2, Wall load: 25 KN/m, Grade of Concrete: M 50 concrete, Grade of Steel: Fe 500, Thickness of shear wall: 450 mm, Seismic zone: V, Important Factor: 1.5, Density of concrete: 25 KN/m3, Type of soil: Type I=Soft Soil, Type II=Medium Soil, Type III= Hard Soil, Response spectra: As per IS 1893(Part-1):2002, Damping of structure: 5 percent & All the analyses has been carried out as per the Indian Standard code books [4-8].  Figure 1: Plan of the Structure I  Figure 2: 3D view showing shear wall location for Structure I  Figure 3: Plan of the Structure II  Figure 4: 3D view showing shear wall location for Structure II   Figure 5: Plan of the Structure III  Figure 6: 3D view showing shear wall location for Structure III  Figure 7: Plan of the Structure IV  Figure 8: 3D view showing shear wall location for Structure IV  Figure 10: 3D view showing shear wall location for Structure V ## IV. RESULTS AND DISCUSSIONS Parametric results in column forces such as column axial force, column moment, column shear force & column torsion with different load combination/load Cases such as 1.2 (DL+LL+EQXP), 1.2 (DL+LL+EQYP), 1.5 (DL+EQXP), 1.5 (DL+EQYP), EQXP & EQYP in different type of soil conditions (soft, medium and hard) were considered, in this regard we compared all column forces in different type of soil condition of structures II, III, IV, V with structure I (plus shape shear wall), also compared forces in hard and medium soils with soft soil for all five structures. Table 1: Column Axial Force, P for structures with the load combination 1.2 (DL+LL+EQXP) & 1.2 (DL+LL+EQYP), All value in "kN" <table><tr><td colspan="5">Column Axial Force, P in Soft Soil</td><td>Struct I</td><td>Struct II</td><td>Struct III</td><td>Struct IV</td><td>Struct V</td></tr><tr><td>Story</td><td>"Column"</td><td>"Unique - Name"</td><td>"Load Case-Combo"</td><td>"Station"m</td><td>"P"</td><td>"P"</td><td>"P"</td><td>"P"</td><td>"P"</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQXP)</td><td>0</td><td>-24171.0618</td><td>-24285.0493</td><td>-24629.8602</td><td>-24381.5444</td><td>-24398.1773</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQXP)</td><td>1.45</td><td>-24103.093</td><td>-24217.0806</td><td>-24561.8915</td><td>-24313.5757</td><td>-24330.2086</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQXP)</td><td>2.9</td><td>-24035.1243</td><td>-24149.1118</td><td>-24493.9227</td><td>-24245.6069</td><td>-24262.2398</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQYP)</td><td>0</td><td>-23630.6382</td><td>-23276.1711</td><td>-23447.6424</td><td>-23345.1752</td><td>-23441.1649</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQYP)</td><td>1.45</td><td>-23562.6694</td><td>-23208.2023</td><td>-23379.6736</td><td>-23277.2065</td><td>-23373.1961</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQYP)</td><td>2.9</td><td>-23494.7007</td><td>-23140.2336</td><td>-23311.7049</td><td>-23209.2377</td><td>-23305.2274</td></tr><tr><td colspan="10">Column Axial Force, P in Medium Soil</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQXP)</td><td>0</td><td>-24937.4993</td><td>-25121.0698</td><td>-25571.6279</td><td>-25446.3503</td><td>-25240.6514</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQXP)</td><td>1.45</td><td>-24869.5305</td><td>-25053.1011</td><td>-25503.6591</td><td>-25378.3816</td><td>-25172.6826</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQXP)</td><td>2.9</td><td>-24801.5618</td><td>-24985.1323</td><td>-25435.6904</td><td>-25310.4128</td><td>-25104.7139</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQYP)</td><td>0</td><td>-24202.5232</td><td>-23748.9954</td><td>-23963.8116</td><td>-23949.6572</td><td>-23939.1144</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQYP)</td><td>1.45</td><td>-24134.5545</td><td>-23681.0267</td><td>-23895.8428</td><td>-23881.6884</td><td>-23871.1456</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQYP)</td><td>2.9</td><td>-24066.5857</td><td>-23613.0579</td><td>-23827.8741</td><td>-23813.7197</td><td>-23803.1769</td></tr><tr><td colspan="10">Column Axial Force, P in Hard Soil</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQXP)</td><td>0</td><td>-25597.4871</td><td>-25840.9764</td><td>-26382.5944</td><td>-26235.5482</td><td>-25966.1151</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQXP)</td><td>1.45</td><td>-25529.5184</td><td>-25773.0076</td><td>-26314.6257</td><td>-26167.5794</td><td>-25898.1464</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQXP)</td><td>2.9</td><td>-25461.5496</td><td>-25705.0389</td><td>-26246.6569</td><td>-26099.6107</td><td>-25830.1776</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQYP)</td><td>0</td><td>-24694.9798</td><td>-24156.1497</td><td>-24408.2906</td><td>-24397.697</td><td>-24367.9043</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQYP)</td><td>1.45</td><td>-24627.011</td><td>-24088.181</td><td>-24340.3219</td><td>-24329.7283</td><td>-24299.9355</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQYP)</td><td>2.9</td><td>-24559.0423</td><td>-24020.2122</td><td>-24272.3531</td><td>-24261.7595</td><td>-24231.9668</td></tr></table> Table 2: Column Moment, M for structures with the load combination 1.2 (DL+LL+EQXP) &1.2 (DL+LL+EQYP), All value in "kN-m" <table><tr><td colspan="5">Column Moment, M in Soft Soil</td><td>Struct I</td><td>Struct I</td><td>Struct II</td><td>Struct II</td><td>Struct III</td><td>Struct IV</td><td>Struct IV</td><td>Struct V</td><td>Struct V</td><td></td></tr><tr><td>Sto ry</td><td>Colu mn</td><td>Uniq ue Name</td><td>Load Case/Com bo</td><td>Stati on m</td><td>&quot;M2&quot;</td><td>&quot;M3&quot;</td><td>&quot;M2&quot;</td><td>&quot;M3&quot;</td><td>&quot;M2&quot;</td><td>&quot;M3&quot;</td><td>&quot;M2&quot;</td><td>&quot;M3&quot;</td><td>&quot;M3&quot;</td><td></td></tr><tr><td>1S T</td><td>C34</td><td>67</td><td>1.2(DL+LL+ EQXP)</td><td>0</td><td>-244.01 18</td><td>979.47 15</td><td>-171.67 74</td><td>1061.1 112</td><td>-251.86 41</td><td>1421.2 435</td><td>-239.99 22</td><td>1271.7 973</td><td>-249.77 58</td><td>971.72 83</td></tr><tr><td>1S T</td><td>C34</td><td>67</td><td>1.2(DL+LL+ EQXP)</td><td>1.45</td><td>-146.26 84</td><td>805.69 93</td><td>-84.416 8</td><td>912.71 96</td><td>-151.39 27</td><td>1219.8 181</td><td>-142.18 6</td><td>1095.4 925</td><td>-150.87 48</td><td>826.99 06</td></tr><tr><td>1S T</td><td>C34</td><td>67</td><td>1.2(DL+LL+ EQXP)</td><td>2.9</td><td>-48.525 1</td><td>631.92 71</td><td>2.8438</td><td>764.32 8</td><td>-50.921 3</td><td>1018.3 927</td><td>-44.379 9</td><td>919.18 78</td><td>-51.973 8</td><td>682.25 29</td></tr><tr><td>1S T</td><td>C34</td><td>67</td><td>1.2(DL+LL+ EQYP)</td><td>0</td><td>1727.5 733</td><td>-24.707 5</td><td>1026.4 07</td><td>-134.63 53</td><td>1218.6 199</td><td>-173.18 54</td><td>-1153.6 344</td><td>-157.40 43</td><td>1174.9 664</td><td>-74.852 3</td></tr><tr><td>1S T</td><td>C34</td><td>67</td><td>1.2(DL+LL+ EQYP)</td><td>1.45</td><td>1393.6 416</td><td>-70.519 4</td><td>-893.97 23</td><td>-94.628</td><td>1027.4 053</td><td>-112.27 58</td><td>-974.88 51</td><td>-107.00 72</td><td>-954.74 75</td><td>-81.408 3</td></tr><tr><td>1S T</td><td>C34</td><td>67</td><td>1.2(DL+LL+ EQYP)</td><td>2.9</td><td>1059.7 1</td><td>-116.33 13</td><td>761.53 75</td><td>-54.620 7</td><td>836.19 07</td><td>-51.366 3</td><td>796.13 58</td><td>-56.610 1</td><td>734.52 87</td><td>-87.964 4</td></tr><tr><td colspan="14">Column Moment, M in Medium Soil</td><td></td></tr><tr><td>1S T</td><td>C34</td><td>67</td><td>1.2(DL+LL+ EQXP)</td><td>0</td><td>-312.52 42</td><td>1329.5 266</td><td>-216.79</td><td>1461.8 423</td><td>-325.85 38</td><td>1958.0 803</td><td>-325.92 7</td><td>1862.7 469</td><td>-322.56 99</td><td>1328.7 543</td></tr><tr><td>1S T</td><td>C34</td><td>67</td><td>1.2(DL+LL+ EQXP)</td><td>1.45</td><td>-197.67 08</td><td>1112.7 719</td><td>-115.99 39</td><td>1264.1 942</td><td>-207.08 2</td><td>1683.6 228</td><td>-206.75 27</td><td>1610.8 77</td><td>-205.97 96</td><td>1142.9 081</td></tr><tr><td>1S T</td><td>C34</td><td>67</td><td>1.2(DL+LL+ EQXP)</td><td>2.9</td><td>-82.817 5</td><td>896.01 72</td><td>-15.197 8</td><td>1066.5 461</td><td>-88.310 2</td><td>1409.1 652</td><td>-87.578 5</td><td>1359.0 072</td><td>-89.389 3</td><td>957.06 19</td></tr><tr><td>1S T</td><td>C34</td><td>67</td><td>1.2(DL+LL+ EQYP)</td><td>0</td><td>2368.8 316</td><td>-36.156 8</td><td>1412.6 049</td><td>-164.37 29</td><td>1674.0 045</td><td>-210.34 29</td><td>1686.2 828</td><td>-200.78 17</td><td>1615.0 795</td><td>-94.595 2</td></tr><tr><td>1S T</td><td>C34</td><td>67</td><td>1.2(DL+LL+ EQYP)</td><td>1.45</td><td>1896.6 069</td><td>-78.885 5</td><td>1214.6 153</td><td>-105.79 85</td><td>1396.0 833</td><td>-128.02 5</td><td>1406.1 652</td><td>-125.34 18</td><td>1297.6 668</td><td>-92.514 4</td></tr><tr><td>1S T</td><td>C34</td><td>67</td><td>1.2(DL+LL+ EQYP)</td><td>2.9</td><td>1424.3 822</td><td>-121.61 42</td><td>1016.6 256</td><td>-47.224 2</td><td>1118.1 621</td><td>-45.707</td><td>1126.0 477</td><td>-49.901 9</td><td>980.25 41</td><td>-90.433 6</td></tr><tr><td colspan="14">Column Moment, M in Hard Soil</td><td></td></tr><tr><td>1S T</td><td>C34</td><td>67</td><td>1.2(DL+LL+ EQXP)</td><td>0</td><td>-371.52 09</td><td>1630.9 629</td><td>-255.63 69</td><td>1806.9 164</td><td>-389.56 71</td><td>2420.3 565</td><td>-389.65 26</td><td>2300.9 465</td><td>-385.25 37</td><td>1636.1 935</td></tr><tr><td>1S T</td><td>C34</td><td>67</td><td>1.2(DL+LL+ EQXP)</td><td>1.45</td><td>-241.93 4</td><td>1377.1 956</td><td>-143.18 53</td><td>1566.8 529</td><td>-255.03 67</td><td>2083.0 102</td><td>-254.63 2</td><td>1993.0 377</td><td>-253.43 1</td><td>1414.9 482</td></tr><tr><td>1S T</td><td>C34</td><td>67</td><td>1.2(DL+LL+ EQXP)</td><td>2.9</td><td>-112.34 71</td><td>1123.4 282</td><td>-30.733 6</td><td>1326.7 894</td><td>-120.50 62</td><td>1745.6 638</td><td>-119.61 13</td><td>1685.1 289</td><td>-121.60 82</td><td>1193.7 03</td></tr><tr><td>1S T</td><td>C34</td><td>67</td><td>1.2(DL+LL+ EQYP)</td><td>0</td><td>2921.0 262</td><td>-46.015 9</td><td>1745.1 642</td><td>-189.98 02</td><td>2066.1 412</td><td>-242.33 97</td><td>2081.2 226</td><td>-232.94 53</td><td>1994.0 659</td><td>-111.59 61</td></tr><tr><td>1S T</td><td>C34</td><td>67</td><td>1.2(DL+LL+ EQYP)</td><td>1.45</td><td>2329.7 158</td><td>-86.089 7</td><td>1490.7 245</td><td>-115.41 76</td><td>1713.5 56</td><td>-141.58 67</td><td>-1725.9 364</td><td>-138.93 69</td><td>1592.9 584</td><td>-102.07 8</td></tr><tr><td>1S T</td><td>C34</td><td>67</td><td>1.2(DL+LL+ EQYP)</td><td>2.9</td><td>1738.4 055</td><td>-126.16 34</td><td>1236.2 848</td><td>-40.855</td><td>1360.9 708</td><td>-40.833 8</td><td>1370.6 502</td><td>-44.928 5</td><td>1191.8 51</td><td>-92.559 9</td></tr></table> Table 3: Column Shear, V for structures with the load combination 1.2 (DL+LL+EQXP) & 1.2 (DL+LL+EQYP), All value in "KN" <table><tr><td colspan="5">Column Shear, V in Soft Soil</td><td>Struct I</td><td>Struct I</td><td>Struct II</td><td>Struct II</td><td>Struct III</td><td>Struct III</td><td>Struct IV</td><td>Struct IV</td><td>Struct V</td><td>Struct V</td></tr><tr><td>Sto ry</td><td>Col umn</td><td>Uniq ue Name</td><td>Load Case/Combo</td><td>Stati on m</td><td>"V2"</td><td>"V3"</td><td>"V2"</td><td>"V3"</td><td>"V2"</td><td>"V3"</td><td>"V2"</td><td>"V3"</td><td>"V2"</td><td>"V3"</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+ EQXP)</td><td>0</td><td>119.8 429</td><td>- 67.40 92</td><td>102.3 39</td><td>- 60.17 98</td><td>138.9 141</td><td>- 69.29 06</td><td>121.5 895</td><td>- 67.45 25</td><td>99.81 91</td><td>- 68.20 76</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+ EQXP)</td><td>1.45</td><td>119.8 429</td><td>- 67.40 92</td><td>102.3 39</td><td>- 60.17 98</td><td>138.9 141</td><td>- 69.29 06</td><td>121.5 895</td><td>- 67.45 25</td><td>99.81 91</td><td>- 68.20 76</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+ EQXP)</td><td>2.9</td><td>119.8 429</td><td>- 67.40 92</td><td>102.3 39</td><td>- 60.17 98</td><td>138.9 141</td><td>- 69.29 06</td><td>121.5 895</td><td>- 67.45 25</td><td>99.81 91</td><td>- 68.20 76</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+ EQYP)</td><td>0</td><td>31.59 44</td><td>230.2 977</td><td>- 27.59 12</td><td>91.33 43</td><td>- 42.00 66</td><td>131.8 722</td><td>- 34.75 66</td><td>123.2 754</td><td>4.521 4</td><td>151.8 751</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+ EQYP)</td><td>1.45</td><td>31.59 44</td><td>230.2 977</td><td>- 27.59 12</td><td>91.33 43</td><td>- 42.00 66</td><td>131.8 722</td><td>- 34.75 66</td><td>123.2 754</td><td>4.521 4</td><td>151.8 7511</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+ EQYP)</td><td>2.9</td><td>31.59 44</td><td>230.2 977</td><td>- 27.59 12</td><td>91.33 43</td><td>- 42.00 66</td><td>131.8 722</td><td>- 34.75 66</td><td>123.2 754</td><td>4.521 4</td><td>151.8 7515</td></tr><tr><td colspan="15">Column Shear, V in Medium Soil</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+ EQXP)</td><td>0</td><td>149.4 86</td><td>- 79.20 92</td><td>136.3 091</td><td>- 69.51 45</td><td>189.2 811</td><td>- 81.91 16</td><td>173.7 034</td><td>- 82.18 92</td><td>128.1 698</td><td>- 80.40 71</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+ EQXP)</td><td>1.45</td><td>149.4 86</td><td>- 79.20 92</td><td>136.3 091</td><td>- 69.51 45</td><td>189.2 811</td><td>- 81.91 16</td><td>173.7 034</td><td>- 82.18 92</td><td>128.1 698</td><td>- 80. 40 71</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+ EQXP)</td><td>2.9</td><td>149.4 86</td><td>- 79.20 92</td><td>136.3 091</td><td>- 69.51 45</td><td>189.2 811</td><td>- 81.91 16</td><td>173.7 034</td><td>- 82.18 92</td><td>128.1 698</td><td>- 80. \({40} \) 71</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+ EQYP)</td><td>0</td><td>29.46 81</td><td>325.6 722</td><td>- 40.39 61</td><td>136.5 446</td><td>- 56.77 1</td><td>191.6 698</td><td>- 52.02 75</td><td>193.1 845</td><td>-1.435</td><td>218.9 053</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+ EQYP)</td><td>1.45</td><td>29.46 81</td><td>325.6 722</td><td>- 40.39 61</td><td>136.5 446</td><td>- 56.77 1</td><td>191.6 698</td><td>- 52.02 75</td><td>193.1 845</td><td>-1.435</td><td>218.9 053</td></tr></table>  Figure 9: Plan of the Structure V  Table 4: Column Torsion, T for structures with the load combination 1.2 (DL+LL+EQXP) & 1.2 (DL+LL+EQYP), All value in "kN-m" <table><tr><td colspan="5">Column Torsion, T in Soft Soil</td><td>Struct I</td><td>Struct II</td><td>Struct III</td><td>Struct IV</td><td>Struct V</td></tr><tr><td>Story</td><td>"Column"</td><td>"Unique-Name"</td><td>"Load Case-Combo"</td><td>"Station"m</td><td>"T"</td><td>"T"</td><td>"T"</td><td>"T"</td><td>"T"</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQXP)</td><td>0</td><td>-41.6175</td><td>-29.3334</td><td>-44.901</td><td>-42.3525</td><td>-43.8436</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQXP)</td><td>1.45</td><td>-41.6175</td><td>-29.3334</td><td>-44.901</td><td>-42.3525</td><td>-43.8436</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQXP)</td><td>2.9</td><td>-41.6175</td><td>-29.3334</td><td>-44.901</td><td>-42.3525</td><td>-43.8436</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQYP)</td><td>0</td><td>45.3145</td><td>31.9525</td><td>48.8724</td><td>46.1375</td><td>48.5638</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQYP)</td><td>1.45</td><td>45.3145</td><td>31.9525</td><td>48.8724</td><td>46.1375</td><td>48.5638</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQYP)</td><td>2.9</td><td>45.3145</td><td>31.9525</td><td>48.8724</td><td>46.1375</td><td>48.5638</td></tr><tr><td colspan="10">Column Torsion, T in Medium Soil</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQXP)</td><td>0</td><td>-56.5981</td><td>-39.8539</td><td>-61.0208</td><td>-61.1008</td><td>-59.584</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQXP)</td><td>1.45</td><td>-56.5981</td><td>-39.8539</td><td>-61.0208</td><td>-61.1008</td><td>-59.584</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQXP)</td><td>2.9</td><td>-56.5981</td><td>-39.8539</td><td>-61.0208</td><td>-61.1008</td><td>-59.584</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQYP)</td><td>0</td><td>61.6294</td><td>43.4949</td><td>66.5111</td><td>66.66</td><td>66.09</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQYP)</td><td>1.45</td><td>61.6294</td><td>43.4949</td><td>66.5111</td><td>66.66</td><td>66.09</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQYP)</td><td>2.9</td><td>61.6294</td><td>43.4949</td><td>66.5111</td><td>66.66</td><td>66.09</td></tr><tr><td colspan="10">Column Torsion, T in Hard Soil</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQXP)</td><td>0</td><td>-69.4981</td><td>-48.9132</td><td>-74.9017</td><td>-75.004</td><td>-73.1383</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQXP)</td><td>1.45</td><td>-69.4981</td><td>-48.9132</td><td>-74.9017</td><td>-75.004</td><td>-73.1383</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQXP)</td><td>2.9</td><td>-69.4981</td><td>-48.9132</td><td>-74.9017</td><td>-75.004</td><td>-73.1383</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQYP)</td><td>0</td><td>75.6784</td><td>53.4342</td><td>81.6999</td><td>81.8788</td><td>81.182</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQYP)</td><td>1.45</td><td>75.6784</td><td>53.4342</td><td>81.6999</td><td>81.8788</td><td>81.182</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQYP)</td><td>2.9</td><td>75.6784</td><td>53.4342</td><td>81.6999</td><td>81.8788</td><td>81.182</td></tr></table> Table 5: Column Axial Force, P for structures with the load combination 1.5 (DL+EQXP) & 1.5 (DL+EQYP), All value in "kN" <table><tr><td colspan="5">Column Axial Force, Pin Soft Soil</td><td>Struct I</td><td>Struct II</td><td>Struct III</td><td>Struct IV</td><td>Struct V</td></tr><tr><td>&quot;Story&quot;</td><td>&quot;Column&quot;</td><td>&quot;Unique-Name&quot;</td><td>&quot;Load Case-Combo&quot;</td><td>&quot;Station&#x27;m</td><td>&quot;P&quot;</td><td>&quot;P&quot;</td><td>&quot;P&quot;</td><td>&quot;P&quot;</td><td>&quot;P&quot;</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQXP)</td><td>0</td><td>-25183.8699</td><td>-25355.396</td><td>-25767.3656</td><td>-25468.0736</td><td>-25450.8356</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQXP)</td><td>1.45</td><td>-25098.9089</td><td>-25270.435</td><td>-25682.4047</td><td>-25383.1127</td><td>-25365.8747</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQXP)</td><td>2.9</td><td>-25013.948</td><td>-25185.4741</td><td>-25597.4437</td><td>-25298.1518</td><td>-25280.9137</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQYP)</td><td>0</td><td>-24508.3404</td><td>-24094.2982</td><td>-24289.5933</td><td>-24172.6121</td><td>-24254.57</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQYP)</td><td>1.45</td><td>-24423.3794</td><td>-24009.3372</td><td>-24204.6324</td><td>-24087.6512</td><td>-24169.6091</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQYP)</td><td>2.9</td><td>-24338.4185</td><td>-23924.3763</td><td>-24119.6714</td><td>-24002.6903</td><td>-24084.6481</td></tr><tr><td colspan="10">Column Axial Force, P in Medium Soil</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQXP)</td><td>0</td><td>-26141.9168</td><td>-26400.4216</td><td>-26944.5752</td><td>-26799.081</td><td>-26503.9282</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQXP)</td><td>1.45</td><td>-26056.9558</td><td>-26315.4607</td><td>-26859.6142</td><td>-26714.1201</td><td>-26418.9672</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQXP)</td><td>2.9</td><td>-25971.9949</td><td>-26230.4998</td><td>-26774.6533</td><td>-26629.1591</td><td>-26334.0063</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQYP)</td><td>0</td><td>-25223.1967</td><td>-24685.3286</td><td>-24934.8048</td><td>-24928.2146</td><td>-24877.0069</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQYP)</td><td>1.45</td><td>-25138.2357</td><td>-24600.3677</td><td>-24849.8439</td><td>-24843.2537</td><td>-24792.046</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQYP)</td><td>2.9</td><td>-25053.2748</td><td>-24515.4068</td><td>-24764.8829</td><td>-24758.2927</td><td>-24707.0851</td></tr><tr><td colspan="10">Column Axial Force, P in Hard Soil</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQXP)</td><td>0</td><td>-26966.9016</td><td>-27300.3048</td><td>-27958.2834</td><td>-27785.5783</td><td>-27410.7578</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQXP)</td><td>1.45</td><td>-26881.9407</td><td>-27215.3439</td><td>-27873.3224</td><td>-27700.6174</td><td>-27325.7969</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQXP)</td><td>2.9</td><td>-26796.9797</td><td>-27130.383</td><td>-27788.3615</td><td>-27615.6564</td><td>-27240.836</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQYP)</td><td>0</td><td>-25838.7674</td><td>-25194.2715</td><td>-25490.4036</td><td>-25488.2644</td><td>-25412.9943</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQYP)</td><td>1.45</td><td>-25753.8064</td><td>-25109.3106</td><td>-25405.4426</td><td>-25403.3035</td><td>-25328.0334</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQYP)</td><td>2.9</td><td>-25668.8455</td><td>-25024.3496</td><td>-25320.4817</td><td>-25318.3425</td><td>-25243.0724</td></tr></table> Table 6: Column Moment, M for structures with the load combination 1.5 (DL +EQXP) & 1.5 (DL+EQYP), All value in "kN-m" <table><tr><td colspan="4">Column Moment, M in Soft Soil</td><td>Struct I</td><td>Struct I</td><td>Struct II</td><td>Struct II</td><td>Struct III</td><td>Struct III</td><td>Struct IV</td><td>Struct IV</td><td>Struct V</td><td>Struct V</td></tr><tr><td>&quot;Story&quot;</td><td>&quot;Column&quot;</td><td>&quot;Unique - Name&quot;</td><td>&quot;Load Case-Combo&quot;</td><td>&quot;Station&quot;m</td><td>&quot;M2&quot;</td><td>&quot;M3&quot;</td><td>&quot;M2&quot;</td><td>&quot;M3&quot;</td><td>&quot;M2&quot;</td><td>&quot;M3&quot;</td><td>&quot;M2&quot;</td><td>&quot;M3&quot;</td><td>&quot;M3&quot;</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+ EQXP)</td><td>0</td><td>-300.97 13</td><td>1225.7 47</td><td>-213.58</td><td>1343.4 34</td><td>-313.8 242</td><td>1800.2 079</td><td>-298.97 71</td><td>1609.5 397</td><td>-311.21 44</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+ EQXP)</td><td>1.45</td><td>-185.76 63</td><td>1027.6 976</td><td>-111.24 83</td><td>1165.8 496</td><td>-194.9 693</td><td>1551.5 389</td><td>-183.46 03</td><td>1395.0 708</td><td>-194.32 03</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+ EQXP)</td><td>2.9</td><td>-70.561 4</td><td>829.64 82</td><td>-8.9167</td><td>988.26 53</td><td>-76.11 45</td><td>1302.8 699</td><td>-67.943 6</td><td>1180.6 019</td><td>-77.426 3</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+ EQYP)</td><td>0</td><td>2163.5 101</td><td>-29.476 6</td><td>1284.0 256</td><td>-151.24 91</td><td>1524. 2808</td><td>-192.82 82</td><td>1443.0 562</td><td>-176.96 23</td><td>1469.7 135</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+ EQYP)</td><td>1.45</td><td>1739.1 213</td><td>-67.575 7</td><td>1111.7 38</td><td>-93.334 9</td><td>1278. 5282</td><td>-113.57 85</td><td>1212.8 786</td><td>-108.05 39</td><td>-84.300 4</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+ EQYP)</td><td>2.9</td><td>1314.7 324</td><td>-105.67 48</td><td>-939.45 04</td><td>-35.420 6</td><td>1032. 7756</td><td>-34.328 8</td><td>982.70 11</td><td>-39.145 4</td><td>-905.70 18</td></tr><tr><td colspan="14">Column Moment, M in Medium Soil</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+ EQXP)</td><td>0</td><td>-386.6 118</td><td>1663.3 159</td><td>-269.97 07</td><td>1844. 3479</td><td>-406.31 13</td><td>2471.2 54</td><td>-406.39 56</td><td>2348.2 268</td><td>-402.20 7</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+ EQXP)</td><td>1.45</td><td>-250.0 193</td><td>1411.5 384</td><td>-150.71 97</td><td>1605. 1929</td><td>-264.58 1</td><td>2131.2 948</td><td>-264.16 87</td><td>2039.3 015</td><td>-263.20 13</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+ EQXP)</td><td>2.9</td><td>-113.4 269</td><td>1159.7 609</td><td>-31.468 7</td><td>1366. 0378</td><td>-122.85 06</td><td>1791.3 356</td><td>-121.94 18</td><td>1730.3 762</td><td>-1226.4 4</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+ EQYP)</td><td>0</td><td>2965. 0829</td><td>-43.788 3</td><td>1766.7 729</td><td>-188.4 211</td><td>2093.5 115</td><td>-239.27 51</td><td>-2108.8 666</td><td>-231.18 4</td><td>-113.43 67</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+ EQYP)</td><td>1.45</td><td>2367. 8278</td><td>-78.033 4</td><td>1512.5 417</td><td>-107.2 981</td><td>1739.3 757</td><td>-133.26 49</td><td>-1751.9 788</td><td>-130.97 2</td><td>-98.183</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+ EQYP)</td><td>2.9</td><td>1770. 5727</td><td>-112.27 85</td><td>1258.3 105</td><td>-26.17 5</td><td>1385.2 398</td><td>-27.254 7</td><td>1395.0 909</td><td>-30.760 1</td><td>-82.929 4</td></tr><tr><td colspan="14">Column Moment, M in Hard Soil</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+ EQXP)</td><td>0</td><td>-460.3 577</td><td>2040.1 114</td><td>-318.52 93</td><td>2275. 6905</td><td>-485.95 3</td><td>3049.0 992</td><td>-486.05 26</td><td>2895.9 762</td><td>-480.56 17</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+ EQXP)</td><td>1.45</td><td>-305.3 483</td><td>1742.0 68</td><td>-184.70 89</td><td>1983. 5162</td><td>-324.52 43</td><td>2630.5 29</td><td>-324.01 77</td><td>2517.0 023</td><td>-322.51 55</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+ EQXP)</td><td>2.9</td><td>-150.3 389</td><td>1444.0 245</td><td>-50.888 5</td><td>1691. 342</td><td>-163.09 56</td><td>-2211.9 588</td><td>-161.98 28</td><td>-2138.0 283</td><td>-164.46 93</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+ EQYP)</td><td>0</td><td>3655. 3261</td><td>-56.112 2</td><td>2182.4 72</td><td>-220.4 303</td><td>2583.6 823</td><td>-279.27 11</td><td>2602.5 414</td><td>-271.38 85</td><td>-134.68 77</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+ EQYP)</td><td>1.45</td><td>2909. 214</td><td>-87.038 6</td><td>1857.6 783</td><td>-119.3 219</td><td>2136.2 165</td><td>-150.21 71</td><td>2151.6 928</td><td>-147.96 59</td><td>-110.13 75</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+ EQYP)</td><td>2.9</td><td>2163. 1019</td><td>-117.96 5</td><td>1532.8 845</td><td>-18.21 35</td><td>1688.7 508</td><td>-21.163 2</td><td>1700.8 441</td><td>-24.543 4</td><td>-85.587 3</td></tr></table> Table 7: Column Shear, V for structures with the load combination 1.5 (DL+EQXP) & 1.5 (DL+EQYP), All value in "kN" <table><tr><td colspan="5">Column Shear, V in Soft Soil</td><td>Struct I</td><td>Struct I</td><td>Struct II</td><td>Struct II</td><td>Struct III</td><td>Struct IV</td><td>Struct IV</td><td>Struct V</td><td>Struct V</td></tr><tr><td>&quot;Story&quot;</td><td>&quot;Column&quot;</td><td>&quot;Unique - Name&quot;</td><td>&quot;Load Case-Combo&quot;</td><td>&quot;Station&quot;m</td><td>&quot;V2&quot;</td><td>&quot;V3&quot;</td><td>&quot;V2&quot;</td><td>&quot;V3&quot;</td><td>&quot;V2&quot;</td><td>&quot;V3&quot;</td><td>&quot;V2&quot;</td><td>&quot;V3&quot;</td><td>&quot;V2&quot;</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+ EQXP)</td><td>0</td><td>136.58 58</td><td>- 79.45 17</td><td>122.47 2</td><td>- 70.573 6</td><td>171.49 59</td><td>- 81.968 9</td><td>147.90 96</td><td>- 79.666 7</td><td>- 116.04 79</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+ EQXP)</td><td>1.45</td><td>136.58 58</td><td>- 79.45 17</td><td>122.47 2</td><td>- 70.573 6</td><td>171.49 59</td><td>- 81.968 9</td><td>147.90 96</td><td>- 79.666 7</td><td>- 116.04 79</td></tr><tr><td>1st</td><td>C34</td><td>67</td><td>1.5(DL+ EQXP)</td><td>2.9</td><td>136.58 58</td><td>- 79.45 17</td><td>122.47 2</td><td>- 70.573 6</td><td>171.49 59</td><td>- 81.968 9</td><td>147.90 96</td><td>- 79.666 7</td><td>- 116.04 79</td></tr><tr><td>1sT</td><td>C34</td><td>67</td><td>1.5(DL+ EQYP)</td><td>0</td><td>26.275 2</td><td>292.6 819</td><td>- 39.940 9</td><td>118.81 9</td><td>- 54.654 9</td><td>169.48 46</td><td>- 47.523 1</td><td>158.74 31</td><td>- 3.0742</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+ EQYP)</td><td>1.45</td><td>26.275 2</td><td>292.6 819</td><td>- 39.940 9</td><td>118.81 9</td><td>- 54.654 9</td><td>169.48 46</td><td>- 47.523 1</td><td>158.74 31</td><td>- 3.0742</td></tr><tr><td>1ST</td><td>C34</td><td></td><td>1.5(DL+ EQYP)</td><td>2.9</td><td>26.275 2</td><td>292.6 819</td><td>- 39.940 9</td><td>118.81 9</td><td>- 54.654 9</td><td>169.48 46</td><td>- 47.523 1</td><td>158.74 31</td><td>- 3.0742</td></tr><tr><td colspan="14">Column Shear, V in Medium Soil</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+ EQXP)</td><td>0</td><td>173.63 97</td><td>- 94.201 7</td><td>164.93 45</td><td>- 82.242 1</td><td>234.45 46</td><td>- 97.745 1</td><td>213.05 19</td><td>- 98.087 5</td><td>- 151.48 63</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+ EQXP)</td><td>1.45</td><td>173.63 97</td><td>- 94.201 7</td><td>164.93 45</td><td>- 82.242 1</td><td>234.45 46</td><td>- 97.745 1</td><td>213.05 19</td><td>- 98.087 5</td><td>- 151.48 63</td></tr><tr><td>lST</td><td>C34</td><td>67</td><td>1.5(DL+ EQXP)</td><td>2.9</td><td>173.63 97</td><td>- 94.201 7</td><td>164.93 45</td><td>- 82.242 1</td><td>234.45 46</td><td>- 97.745 1</td><td>213.05 19</td><td>- 98.087 5</td><td>- 151.48 63</td></tr><tr><td>IST</td><td>C34</td><td>67</td><td>1.5(DL+ EQYP)</td><td>0</td><td>23.617 3</td><td>411.90 01</td><td>- 55.946 9</td><td>175.33 19</td><td>- 73.110 5</td><td>244.23 16</td><td>- 69.111 7</td><td>246.12 96</td><td>- 10.519 7</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+ EQYP)</td><td>1.45</td><td>23.617 3</td><td>411.90 01</td><td>- 55.946 9</td><td>175.33 19</td><td>- 73.110 5</td><td>244.23 16</td><td>- 69.111 7</td><td>246.12 96</td><td>- 10.519 7</td></tr><tr><td>1ST</td><td>c34</td><td>67</td><td>1.5(DL+ EQYP)</td><td>2.9</td><td>23.617 3</td><td>411.90 01</td><td>- 55.946 9</td><td>175.33 19</td><td>- 73.110 5</td><td>244.23 16</td><td>- 69.111 7</td><td>246.12 96</td><td>- 10.519 7</td></tr><tr><td colspan="14">Column Shear, V in Hard Soil</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+ EQXP)</td><td>0</td><td>205.54 72</td><td>- 106.90 31</td><td>201.49 95</td><td>- 92.289 9</td><td>288.66 91</td><td>- 111.33 02</td><td>261.36 13</td><td>- 111.74 82</td><td>- 182.00 27</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+ EQXP)</td><td>1.45</td><td>205.54 72</td><td>- 106.90 31</td><td>201.49 95</td><td>- 92.289 9</td><td>288.66 91</td><td>- 111.33 02</td><td>261.36 13</td><td>- 111.74 82</td><td>- 182.00 27&#x27;</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+ EQXP)</td><td>2.9</td><td>205.54 72</td><td>- 106.90 31</td><td>201.49 95</td><td>- 92.289 9</td><td>288.66 91</td><td>- 111.33 02</td><td>261.36 13</td><td>- 111.74 82</td><td>- 182.00 27'</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+ EQYP)</td><td>0</td><td>21.328 5</td><td>514.56 01</td><td>- 69.729 9</td><td>223.99 57</td><td>- 89.002 7</td><td>308.59 71</td><td>- 85.119</td><td>310.93 01</td><td>- 16.931 2</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+ EQYP)</td><td>1.45</td><td>21.328 5</td><td>514.56 01</td><td>- 69.729 9</td><td>223.99 57</td><td>- 89.002 7</td><td>308.59 71</td><td>- 85.119</td><td>310.93 01</td><td>- 16.931 2</td></tr><tr><td>1ST</td><td>C3A</td><td>67</td><td>1.5(DL+ EQYP)</td><td>2.9</td><td>21.328 5</td><td>514.56 01</td><td>- 69.729 9</td><td>223.99 57</td><td>- 89.002 7</td><td>308.59 71</td><td>- 85.119</td><td>310.93 01</td><td>- 16.931 2</td></tr></table> Table 8: Column Torsion, T for structures with the load combination 1.5 (DL+EQXP) & 1.5 (DL+EQYP), All value in "kN-m" <table><tr><td colspan="5">Column Torsion, T in Soft Soil</td><td>Struct I</td><td>Struct II</td><td>Struct III</td><td>Struct IV</td><td>Struct V</td></tr><tr><td>&quot;Story&quot;</td><td>&quot;Column&quot;</td><td>&quot;Unique-Name&quot;</td><td>&quot;Load Case-Combo&quot;</td><td>&quot;Station&#x27;m</td><td>&quot;T&quot;</td><td>&quot;T&quot;</td><td>&quot;T&quot;</td><td>&quot;T&quot;</td><td>&quot;T&quot;</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQXP)</td><td>0</td><td>-52.0172</td><td>-36.6355</td><td>-56.0881</td><td>-52.909</td><td>-54.7871</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQXP)</td><td>1.45</td><td>-52.0172</td><td>-36.6355</td><td>-56.0881</td><td>-52.909</td><td>-54.7871</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQXP)</td><td>2.9</td><td>-52.0172</td><td>-36.6355</td><td>-56.0881</td><td>-52.909</td><td>-54.7871</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQYP)</td><td>0</td><td>56.6478</td><td>39.9718</td><td>61.1286</td><td>57.7035</td><td>60.7221</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQYP)</td><td>1.45</td><td>56.6478</td><td>39.9718</td><td>61.1286</td><td>57.7035</td><td>60.7221</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQYP)</td><td>2.9</td><td>56.6478</td><td>39.9718</td><td>61.1286</td><td>57.7035</td><td>60.7221</td></tr><tr><td colspan="10">Column Torsion, T in Medium Soil</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQXP)</td><td>0</td><td>-70.743</td><td>-49.7861</td><td>-76.2378</td><td>-76.3444</td><td>-74.4626</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQXP)</td><td>1.45</td><td>-70.743</td><td>-49.7861</td><td>-76.2378</td><td>-76.3444</td><td>-74.4626</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQXP)</td><td>2.9</td><td>-70.743</td><td>-49.7861</td><td>-76.2378</td><td>-76.3444</td><td>-74.4626</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQYP)</td><td>0</td><td>77.0414</td><td>54.3999</td><td>83.1769</td><td>83.3566</td><td>82.6299</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQYP)</td><td>1.45</td><td>77.0414</td><td>54.3999</td><td>83.1769</td><td>83.3566</td><td>82.6299</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQYP)</td><td>2.9</td><td>77.0414</td><td>54.3999</td><td>83.1769</td><td>83.3566</td><td>82.6299</td></tr><tr><td colspan="10">Column Torsion, T in Hard Soil</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQXP)</td><td>0</td><td>-86.8679</td><td>-61.1102</td><td>-93.589</td><td>-93.7234</td><td>-91.4055</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQXP)</td><td>1.45</td><td>-86.8679</td><td>-61.1102</td><td>-93.589</td><td>-93.7234</td><td>-91.4055</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQXP)</td><td>2.9</td><td>-86.8679</td><td>-61.1102</td><td>-93.589</td><td>-93.7234</td><td>-91.4055</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQYP)</td><td>0</td><td>94.6026</td><td>66.824</td><td>102.1629</td><td>102.3801</td><td>101.4949</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQYP)</td><td>1.45</td><td>94.6026</td><td>66.824</td><td>102.1629</td><td>102.3801</td><td>101.4949</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQYP)</td><td>2.9</td><td>94.6026</td><td>66.824</td><td>102.1629</td><td>102.3801</td><td>101.4949</td></tr></table> Table 9: Column Axial Force, P for structures with the load Cases EQXP & EQYP, All value in "kN" <table><tr><td colspan="5">Column Axial Force, P in Soft Soil</td><td>Struct I</td><td>Struct II</td><td>Struct III</td><td>Struct IV</td><td>Struct V</td></tr><tr><td>&quot;Story&quot;</td><td>&quot;Column&quot;</td><td>&quot;Unique-Name&quot;</td><td>&quot;Load Case-Combo&quot;</td><td>&quot;Station)m</td><td>&quot;P&quot;</td><td>&quot;P&quot;</td><td>&quot;P&quot;</td><td>&quot;P&quot;</td><td>&quot;P&quot;</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQXP</td><td>0</td><td>-1774.1609</td><td>-1935.2327</td><td>-2180.0176</td><td>-1997.9011</td><td>-1950.1714</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQXP</td><td>1.45</td><td>-1774.1609</td><td>-1935.2327</td><td>-2180.0176</td><td>-1997.9011</td><td>-1950.1714</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQXP</td><td>2.9</td><td>-1774.1609</td><td>-1935.2327</td><td>-2180.0176</td><td>-1997.9011</td><td>-1950.1714</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQYP</td><td>0</td><td>-1323.8079</td><td>-1094.5008</td><td>-1194.8361</td><td>-1134.2601</td><td>-1152.661</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQYP</td><td>1.45</td><td>-1323.8079</td><td>-1094.5008</td><td>-1194.8361</td><td>-1134.2601</td><td>-1152.661</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQYP</td><td>2.9</td><td>-1323.8079</td><td>-1094.5008</td><td>-1194.8361</td><td>-1134.2601</td><td>-1152.661</td></tr><tr><td colspan="10">Column Axial Force, P in Medium Soil</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQXP</td><td>0</td><td>-2412.8589</td><td>-2631.9165</td><td>-2964.824</td><td>-2885.2394</td><td>-2652.2331</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQXP</td><td>1.45</td><td>-2412.8589</td><td>-2631.9165</td><td>-2964.824</td><td>-2885.2394</td><td>-2652.2331</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQXP</td><td>2.9</td><td>-2412.8589</td><td>-2631.9165</td><td>-2964.824</td><td>-2885.2394</td><td>-2652.2331</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQYP</td><td>0</td><td>-1800.3788</td><td>-1488.5211</td><td>-1624.9771</td><td>-1637.9951</td><td>-1567.6189</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQYP</td><td>1.45</td><td>-1800.3788</td><td>-1488.5211</td><td>-1624.9771</td><td>-1637.9951</td><td>-1567.6189</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQYP</td><td>2.9</td><td>-1800.3788</td><td>-1488.5211</td><td>-1624.9771</td><td>-1637.9951</td><td>-1567.6189</td></tr><tr><td colspan="10">Column Axial Force, P in Hard Soil</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQXP</td><td>0</td><td>-2962.8488</td><td>-3231.8386</td><td>-3640.6295</td><td>-3542.9042</td><td>-3256.7862</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQXP</td><td>1.45</td><td>-2962.8488</td><td>-3231.8386</td><td>-3640.6295</td><td>-3542.9042</td><td>-3256.7862</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQXP</td><td>2.9</td><td>-2962.8488</td><td>-3231.8386</td><td>-3640.6295</td><td>-3542.9042</td><td>-3256.7862</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQYP</td><td>0</td><td>-2210.7593</td><td>-1827.8164</td><td>-1995.3763</td><td>-2011.3616</td><td>-1924.9438</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQYP</td><td>1.45</td><td>-2210.7593</td><td>-1827.8164</td><td>-1995.3763</td><td>-2011.3616</td><td>-1924.9438</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQYP</td><td>2.9</td><td>-2210.7593</td><td>-1827.8164</td><td>-1995.3763</td><td>-2011.3616</td><td>-1924.9438</td></tr></table> Table 10: Column Moment, M for structures with the load Cases EQXP & EQYP, All value in "kN-m" <table><tr><td colspan="5">Column Moment, M in Soft Soil</td><td>Struct I</td><td>Struct I</td><td>Struct II</td><td>Struct II</td><td>Struct III</td><td>Struct III</td><td>Struct IV</td><td>Struct IV</td><td>Struct V</td><td>Struc t V</td></tr><tr><td>&quot;Story&quot;</td><td>&quot;Column&quot;</td><td>&quot;Unique- Name&quot;</td><td>&quot;Load Case- Combo&quot;</td><td>&quot;Station&quot;m</td><td>&quot;M2&quot;</td><td>&quot;M3&quot;</td><td>&quot;M2&quot;</td><td>&quot;M3&quot;</td><td>&quot;M2&quot;</td><td>&quot;M3&quot;</td><td>&quot;M2&quot;</td><td>&quot;M3&quot;</td><td>&quot;M2&quot;</td><td>&quot;M3&quot;</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQXP</td><td>0</td><td>-158.5935</td><td>810.312 8</td><td>- 104.427 2</td><td>927.618 4</td><td>- 171.27 25</td><td>1242.67 79</td><td>- 161.363</td><td>1109. 5618</td><td>- 168.5 048</td><td>826.4 492</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQXP</td><td>1.45</td><td>-118.987</td><td>710.816 2</td><td>- 73.0951</td><td>813.598 6</td><td>- 128.91 04</td><td>1073.62 19</td><td>- 121.236 7</td><td>967.6 594</td><td>- 127.5 574</td><td>731.2 906</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQXP</td><td>2.9</td><td>-79.3805</td><td>611.319 7</td><td>-41.763</td><td>699.578 8</td><td>- 86.548 4</td><td>904.566</td><td>- 81.1104</td><td>825.7 569</td><td>- 86.60 99</td><td>636.1 319</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQYP</td><td>0</td><td>1484.394 1</td><td>-26.503</td><td>893.976 6</td><td>-68.837</td><td>1054.1 309</td><td>- 86.0128</td><td>999.992 5</td><td>- 81.43 95</td><td>1018. 7804</td><td>- 45.70 12</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQYP</td><td>1.45</td><td>1164.271 4</td><td>-19.366</td><td>742.229 1</td><td>- 25.8578</td><td>- 36.4563</td><td>- 36.4563</td><td>- 34.42 38</td><td>- 793.7 946</td><td>- 25.70 85</td><td></td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQYP</td><td>2.9</td><td>844.1487</td><td>-12.229</td><td>590.481 7</td><td>17.1215</td><td>652.71 16</td><td>13.1002</td><td>619.319 3</td><td>12.59 2</td><td>568.8 088</td><td>- 5.715 8</td></tr><tr><td colspan="15">Column Moment, M in Medium Soil</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQXP</td><td>0</td><td>- 215.6871</td><td>1102.02 54</td><td>- 142.020 9</td><td>1261.56 1</td><td>- 232.93 06</td><td>1690.04 19</td><td>- 232.975 4</td><td>1602.0 199</td><td>- 229.16 66</td><td>1123.971</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQXP</td><td>1.45</td><td>- 161.8223</td><td>966.710 1</td><td>- 99.4093</td><td>1106.49 41</td><td>- 175.31 82</td><td>1460.12 58</td><td>- 175.042 3</td><td>1397.1 465</td><td>- 173.47 8</td><td>994. 5552</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQXP</td><td>2.9</td><td>- 107.9575</td><td>831.394 8</td><td>- 56.7977</td><td>951.427 1</td><td>- 117.70 58</td><td>1230.20 98</td><td>- 117.109 3</td><td>1192.2 73</td><td>- 117.78 95</td><td>865. 1394</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQYP</td><td>0</td><td>2018.776</td><td>- 36.0441</td><td>1215.80 81</td><td>- 93.6183</td><td>1433.6 18</td><td>- 116.977 5</td><td>1443.86 61</td><td>- 117.58 73</td><td>1385.5 413</td><td>- 62.1 537</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQYP</td><td>1.45</td><td>1583.409 1</td><td>- 26.3378</td><td>1009.43 16</td><td>- 35.1666</td><td>1160.6 529</td><td>- 49.5806</td><td>- 49.702 6</td><td>- 49.702 5</td><td>1079.5 607</td><td>- 34.9 636</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQYP</td><td>2.9</td><td>1148.042 2</td><td>- 16.6314</td><td>803.055 1</td><td>23.2852</td><td>887.68 78</td><td>17.8162</td><td>894.245 9</td><td>18.182 2</td><td>773.58</td><td>- 7.77 35</td></tr><tr><td colspan="15">Column Moment, M in Hard Soil</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQXP</td><td>0</td><td>- 264.8511</td><td>1353.22 23</td><td>- 174.393 4</td><td>1549.12 27</td><td>- 286.02 51</td><td>2075.27 21</td><td>-286.08</td><td>1967.1 862</td><td>- 281.40 31</td><td>1380.170 2</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQXP</td><td>1.45</td><td>- 198.7083</td><td>1187.06 31</td><td>- 122.068 8</td><td>1358.70 96</td><td>- 215.28 04</td><td>1792.94 86</td><td>- 214.941 7</td><td>1715.6 137</td><td>- 213.02 08</td><td>1221.255 3</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQXP</td><td>2.9</td><td>- 132.5655</td><td>1020.90 39</td><td>- 69.7443</td><td>1168.29 65</td><td>- 144.53 58</td><td>1510.62 52</td><td>- 143.803 3</td><td>1464.0 411</td><td>- 144.63 86</td><td>1062.340 3</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQYP</td><td>0</td><td>2478.938 1</td><td>-44.26</td><td>1492.94 09</td><td>- 114.957 8</td><td>1760.3 985</td><td>- 143,641 4</td><td>1772.98 27</td><td>- 144.39 03</td><td>1701.3 633</td><td>- 76.3 21</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQYP</td><td>1.45</td><td>1944.333 2</td><td>- 32.3412</td><td>1239.52 26</td><td>- 43.1825</td><td>1425.2 135</td><td>- 60.8821</td><td>1435.53 2</td><td>- 61.031 8</td><td>1325.6 37</td><td>- 42.9 332</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQYP</td><td>2.9</td><td>1409.728 3</td><td>- 20.4224</td><td>986.104 4</td><td>28.5929</td><td>1090.0 284</td><td>21.8773</td><td>1098.08 13</td><td>22.326 7</td><td>949.91 07</td><td>- 9.54 54</td></tr></table> Table 11: Column Shear, V for structures with the load Cases EQXP & EQYP, All value in "kN" <table><tr><td colspan="5">Column Shear, V in Soft Soil</td><td>Struct I</td><td>Struct I</td><td>Struct II</td><td>Struct II</td><td>Struct III</td><td>Struct III</td><td>Struct IV</td><td>Struct IV</td><td>Struct V</td><td>Struct V</td></tr><tr><td>&quot;Story&quot;</td><td>&quot;Column&quot;</td><td>&quot;Unique - Name&quot;</td><td>&quot;Load Case-Combo&quot;</td><td>&quot;Station&#x27;m</td><td>&quot;V2&quot;</td><td>&quot;V3&quot;</td><td>&quot;V2&quot;</td><td>&quot;V3&quot;</td><td>&quot;V2&quot;</td><td>&quot;V3&quot;</td><td>&quot;V2&quot;</td><td>&quot;V3&quot;</td><td>&quot;V2&quot;</td><td>&quot;V3&quot;</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQXP</td><td>0</td><td>68.6183</td><td>-27.3148</td><td>78.6344</td><td>-21.6083</td><td>116.590 3</td><td>-29.2152</td><td>97.8638</td><td>-27.6733</td><td>65.62 67</td><td>-28.2396</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQXP</td><td>1.45</td><td>68.6183</td><td>-27.3148</td><td>78.6344</td><td>-21.6083</td><td>116.590 3</td><td>-29.2152</td><td>97.8638</td><td>-27.6733</td><td>65.62 67</td><td>-28.2396</td></tr><tr><td>1ST</td><td>C34</td><td>66</td><td>EQXP</td><td>2.9</td><td>68.6183</td><td>-27.3148</td><td>78.6344</td><td>-21.6083</td><td>116.590 3</td><td>-29.2152</td><td>97.8638</td><td>-27.6733</td><td>65.62 67</td><td>-28.2396</td></tr><tr><td>1ST</td><td>C34</td><td>65</td><td>EQYP</td><td>0</td><td>-4.9221</td><td>220.774 3</td><td>-29.6409</td><td>104.653 4</td><td>-34.1769</td><td>138.420 4</td><td>-32.4246</td><td>131.2666</td><td>-13.78 81</td><td>155.162 6</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQYP</td><td>1.45</td><td>-4.9221</td><td>220.774 3</td><td>-29.6409</td><td>104.653 4</td><td>-34.1769</td><td>138.420 4</td><td>-32.4246</td><td>131.2666</td><td>-13.78 81</td><td>155.162 6</td></tr><tr><td>1ST C34</td><td>67</td><td>EQYP</td><td>2.9</td><td>-4.9221</td><td>220.774 3</td><td>-29.6409</td><td>104.653 4</td><td>-34.1769</td><td>138.420 4</td><td>-32.4246</td><td>131.2666</td><td>-13.78 81</td><td>155.162 6</td><td></td></tr><tr><td colspan="15">Column Shear, V in Medium Soil</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQXP</td><td>0</td><td>93.3209</td><td>-37.1481</td><td>106.942 7</td><td>-29.3873</td><td>158.562 8</td><td>-39.7327</td><td>141.292</td><td>-39.9538</td><td>89.2523</td><td>-38.4059</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQXP</td><td>1.45</td><td>93.3209</td><td>-37.1481</td><td>106.942 7</td><td>-29.3873</td><td>158.562 8</td><td>-39.7327</td><td>141.292</td><td>-39.9538</td><td>89.2523</td><td>-38.4059</td></tr><tr><td>1ST</td><td>C34</td><td>C7</td><td>EQXP</td><td>2.9</td><td>93.3209</td><td>-37.1481</td><td>106.942 7</td><td>-29.3873</td><td>158.562 8</td><td>-39.7327</td><td>141.292</td><td>-39.9538</td><td>89.2523</td><td>-38.4059</td></tr><tr><td>1ST</td><td>C34</td><td>B7</td><td>EQYP</td><td>0</td><td>-6.694</td><td>300.253</td><td>-40.3116</td><td>142.328 6</td><td>-46.4806</td><td>188.251 8</td><td>-46.8171</td><td>189.524 2</td><td>-18.7518</td><td>211.021 2</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQYP</td><td>1.45</td><td>-6.694</td><td>300.253</td><td>-40.3116</td><td>142.328 6</td><td>-46.4806</td><td>188.251 8</td><td>-46.8171</td><td>189.524 2</td><td>-18.7518</td><td>211.021 2</td></tr><tr><td>1ST</td><td>C33</td><td>67</td><td>EQYP</td><td>2.9</td><td>-6.694</td><td>300.253</td><td>-40.3116</td><td>142.328 6</td><td>-46.4806</td><td>188.251 8</td><td>-46.8171</td><td>189.524 2</td><td>-18.7518</td><td>211.021 2</td></tr><tr><td colspan="15">Column Shear, V in Hard Soil</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQXP</td><td>0</td><td>114.592 6</td><td>-45.6157</td><td>131.319 4</td><td>-36.0859</td><td>194.705 8</td><td>-48.7894</td><td>173.498 3</td><td>-49.0609</td><td>109.596 5</td><td>-47.1602</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQXP</td><td>1.45</td><td>114.592 6</td><td>-45.6157</td><td>131.319 4</td><td>-36.0859</td><td>194.705 8</td><td>-48.7894</td><td>173.498 3</td><td>-49.0609</td><td>109.596 5</td><td>-47.1602</td></tr><tr><td>1 ST</td><td>C34</td><td>67</td><td>EQXP</td><td>2.9</td><td>114.592 6</td><td>-45.6157</td><td>131.319 4</td><td>-36.0859</td><td>194.705 8</td><td>-48.7894</td><td>173.498 3</td><td>-49.0609</td><td>109.596 5</td><td>-47.1602</td></tr><tr><td>1(ST)</td><td>C34</td><td>67</td><td>EQYP</td><td>0</td><td>-8.2199</td><td>368.693</td><td>-49.5002</td><td>174.771 2</td><td>-57.0754</td><td>231.162 1</td><td>-57.4886</td><td>232.724 6</td><td>-23.0261</td><td>259.121 6</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQYP</td><td>1.45</td><td>-8.2199</td><td>368.693</td><td>-49.5002</td><td>174.771 2</td><td>-57.0754</td><td>231.162 1</td><td>-57.4886</td><td>232.724 6</td><td>-23.0261</td><td>259.121 6</td></tr><tr><td>1ST</td><td>C 34</td><td>67</td><td>EQYP</td><td>2.9</td><td>-8.2199</td><td>368.693</td><td>-49.5002</td><td>174.771 2</td><td>-57.0754</td><td>231.162 1</td><td>-57.4886</td><td>232.724 6</td><td>-23.0261</td><td>259.121 6</td></tr></table> Table 12: Column Torsion, T for structures with the load Cases EQXP & EQYP, All value in "kN-m" <table><tr><td colspan="5">Column Torsion, T in Soft Soil</td><td>Struct I</td><td>Struct II</td><td>Struct III</td><td>Struct IV</td><td>Struct V</td></tr><tr><td>&quot;Story&quot;</td><td>&quot;Column&quot;</td><td>&quot;Unique-Name&quot;</td><td>&quot;Load Case-Combo&quot;</td><td>&quot;Station&#x27;m</td><td>&quot;T&quot;</td><td>&quot;T&quot;</td><td>&quot;T&quot;</td><td>&quot;T&quot;</td><td>&quot;T&quot;</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQXP</td><td>0</td><td>-34.6774</td><td>-24.353</td><td>-37.3143</td><td>-35.2051</td><td>-36.4362</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQXP</td><td>1.45</td><td>-34.6774</td><td>-24.353</td><td>-37.3143</td><td>-35.2051</td><td>-36.4362</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQXP</td><td>2.9</td><td>-34.6774</td><td>-24.353</td><td>-37.3143</td><td>-35.2051</td><td>-36.4362</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQYP</td><td>0</td><td>37.766</td><td>26.7186</td><td>40.8301</td><td>38.5365</td><td>40.5699</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQYP</td><td>1.45</td><td>37.766</td><td>26.7186</td><td>40.8301</td><td>38.5365</td><td>40.5699</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQYP</td><td>2.9</td><td>37.766</td><td>26.7186</td><td>40.8301</td><td>38.5365</td><td>40.5699</td></tr><tr><td colspan="10">Column Torsion, T in Medium Soil</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQXP</td><td>0</td><td>-47.1612</td><td>-33.12</td><td>-50.7475</td><td>-50.8287</td><td>-49.5533</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQXP</td><td>1.45</td><td>-47.1612</td><td>-33.12</td><td>-50.7475</td><td>-50.8287</td><td>-49.5533</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQXP</td><td>2.9</td><td>-47.1612</td><td>-33.12</td><td>-50.7475</td><td>-50.8287</td><td>-49.5533</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQYP</td><td>0</td><td>51.3617</td><td>36.3373</td><td>55.529</td><td>55.6386</td><td>55.1751</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQYP</td><td>1.45</td><td>51.3617</td><td>36.3373</td><td>55.529</td><td>55.6386</td><td>55.1751</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQYP</td><td>2.9</td><td>51.3617</td><td>36.3373</td><td>55.529</td><td>55.6386</td><td>55.1751</td></tr><tr><td colspan="10">Column Torsion, T in Hard Soil</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQXP</td><td>0</td><td>-57.9112</td><td>-40.6695</td><td>-62.315</td><td>-62.4147</td><td>-60.8485</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQXP</td><td>1.45</td><td>-57.9112</td><td>-40.6695</td><td>-62.315</td><td>-62.4147</td><td>-60.8485</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQXP</td><td>2.9</td><td>-57.9112</td><td>-40.6695</td><td>-62.315</td><td>-62.4147</td><td>-60.8485</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQYP</td><td>0</td><td>63.0692</td><td>44.62</td><td>68.1863</td><td>68.321</td><td>67.7517</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQYP</td><td>1.45</td><td>63.0692</td><td>44.62</td><td>68.1863</td><td>68.321</td><td>67.7517</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQYP</td><td>2.9</td><td>63.0692</td><td>44.62</td><td>68.1863</td><td>68.321</td><td>67.7517</td></tr></table>    <table><tr><td colspan="3">Modal Load Participation Ratios</td><td>Struct I</td><td>Struct I</td><td>Struct II</td><td>Struct II</td><td>Struct III</td><td>Struct III</td><td>Struct IV</td><td>Struct IV</td><td>Struct V</td><td>Struct V</td></tr><tr><td>&quot;Case&quot;</td><td>&quot;Item Type&quot;</td><td>&quot;Item&quot;</td><td>&quot;Static&quot;</td><td>&quot;Dynamic&quot;</td><td>&quot;Static&quot;</td><td>&quot;Dynamic&quot;</td><td>&quot;Static&quot;</td><td>&quot;Dynamic&quot;</td><td>&quot;Static&quot;</td><td>&quot;Dynamic&quot;</td><td>&quot;Static&quot;</td><td>&quot;Dynamic&quot;</td></tr><tr><td></td><td></td><td></td><td>%</td><td>%</td><td>%</td><td>%</td><td>%</td><td>%</td><td>%</td><td>%</td><td>%</td><td>%</td></tr><tr><td>Modal</td><td>Acceleration</td><td>UX</td><td>99.82</td><td>86.71</td><td>99.99</td><td>94.7</td><td>99.98</td><td>94.59</td><td>99.99</td><td>94.54</td><td>99.97</td><td>91.54</td></tr><tr><td>Modal</td><td>Acceleration</td><td>UY</td><td>99.79</td><td>87.46</td><td>99.98</td><td>91.46</td><td>99.97</td><td>91.85</td><td>99.97</td><td>91.83</td><td>99.97</td><td>92.51</td></tr><tr><td>Modal</td><td>Acceleration</td><td>UZ</td><td>0</td><td>0</td><td>0</td><td>0</td><td>0</td><td>0</td><td>0</td><td>0</td><td>0</td><td>0</td></tr></table> <table><tr><td colspan="3">Modal Load Participation Ratios</td><td>Struct I</td><td>Struct I</td><td>Struct II</td><td>Struct II</td><td>Struct III</td><td>Struct III</td><td>Struct IV</td><td>Struct IV</td><td>Struct V</td><td>Struct V</td></tr><tr><td>&quot;Case&quot;</td><td>&quot;Item Type&quot;</td><td>&quot;Item&quot;</td><td>&quot;Static&quot;</td><td>&quot;Dynamic&quot;</td><td>&quot;Static&quot;</td><td>&quot;Dynamic&quot;</td><td>&quot;Static&quot;</td><td>&quot;Dynamic&quot;</td><td>&quot;Static&quot;</td><td>&quot;Dynamic&quot;</td><td>&quot;Static&quot;</td><td>&quot;Dynamic&quot;</td></tr><tr><td></td><td></td><td></td><td>%</td><td>%</td><td>%</td><td>%</td><td>%</td><td>%</td><td>%</td><td>%</td><td>%</td><td>%</td></tr><tr><td>Modal</td><td>Acceleration</td><td>UX</td><td>99.82</td><td>86.71</td><td>99.99</td><td>94.7</td><td>99.98</td><td>94.59</td><td>99.99</td><td>94.54</td><td>99.97</td><td>91.54</td></tr><tr><td>Modal</td><td>Acceleration</td><td>UY</td><td>99.79</td><td>87.46</td><td>99.98</td><td>91.46</td><td>99.97</td><td>91.85</td><td>99.97</td><td>91.83</td><td>99.97</td><td>92.51</td></tr><tr><td>Modal</td><td>Acceleration</td><td>UZ</td><td>0</td><td>0</td><td>0</td><td>0</td><td>0</td><td>0</td><td>0</td><td>0</td><td>0</td><td>0</td></tr></table>  Graph 1: Modal Load Participation Ratios of Structures Table 14: Modal Periods and Frequencies <table><tr><td colspan="4">Struct I</td><td colspan="2">Struct II</td><td colspan="2">Struct III</td><td colspan="2">Struct IV</td><td colspan="2">Struct V</td></tr><tr><td>Case</td><td>Mode</td><td>Period</td><td>Frequency</td><td>Period</td><td>Frequency</td><td>Period</td><td>Frequency</td><td>Period</td><td>Frequency</td><td>Period</td><td>Frequency</td></tr><tr><td></td><td></td><td>sec</td><td>cyc/sec</td><td>sec</td><td>cyc/sec</td><td>sec</td><td>cyc/sec</td><td>sec</td><td>cyc/sec</td><td>sec</td><td>cyc/sec</td></tr><tr><td>Modal</td><td>1</td><td>6.298</td><td>0.159</td><td>5.785</td><td>0.173</td><td>6.415</td><td>0.156</td><td>6.375</td><td>0.157</td><td>6.382</td><td>0.157</td></tr><tr><td>Modal</td><td>2</td><td>6.248</td><td>0.16</td><td>5.606</td><td>0.178</td><td>6.32</td><td>0.158</td><td>6.21</td><td>0.161</td><td>5.694</td><td>0.176</td></tr><tr><td>Modal</td><td>3</td><td>5.545</td><td>0.18</td><td>4.684</td><td>0.213</td><td>5.767</td><td>0.173</td><td>5.792</td><td>0.173</td><td>5.642</td><td>0.177</td></tr><tr><td>Modal</td><td>4</td><td>2.062</td><td>0.485</td><td>1.701</td><td>0.588</td><td>2.114</td><td>0.473</td><td>2.102</td><td>0.476</td><td>2.088</td><td>0.479</td></tr><tr><td>Modal</td><td>5</td><td>1.952</td><td>0.512</td><td>1.547</td><td>0.646</td><td>1.958</td><td>0.511</td><td>1.901</td><td>0.526</td><td>1.565</td><td>0.639</td></tr><tr><td>Modal</td><td>6</td><td>1.603</td><td>0.624</td><td>1.475</td><td>0.678</td><td>1.568</td><td>0.638</td><td>1.575</td><td>0.635</td><td>1.524</td><td>0.656</td></tr><tr><td>Modal</td><td>7</td><td>1.191</td><td>0.84</td><td>0.9</td><td>1.112</td><td>1.219</td><td>0.82</td><td>1.212</td><td>0.825</td><td>1.19</td><td>0.84</td></tr><tr><td>Modal</td><td>8</td><td>1.027</td><td>0.974</td><td>0.838</td><td>1.193</td><td>1.028</td><td>0.972</td><td>0.983</td><td>1.017</td><td>0.791</td><td>1.264</td></tr><tr><td>Modal</td><td>9</td><td>0.803</td><td>1.245</td><td>0.645</td><td>1.551</td><td>0.82</td><td>1.22</td><td>0.815</td><td>1.226</td><td>0.711</td><td>1.406</td></tr><tr><td>Modal</td><td>10</td><td>0.782</td><td>1.279</td><td>0.613</td><td>1.632</td><td>0.711</td><td>1.406</td><td>0.714</td><td>1.401</td><td>0.703</td><td>1.423</td></tr><tr><td>Modal</td><td>11</td><td>0.645</td><td>1.55</td><td>0.5</td><td>2.002</td><td>0.641</td><td>1.56</td><td>0.604</td><td>1.656</td><td>0.565</td><td>1.769</td></tr><tr><td>Modal</td><td>12</td><td>0.581</td><td>1.72</td><td>0.45</td><td>2.222</td><td>0.592</td><td>1.689</td><td>0.589</td><td>1.697</td><td>0.423</td><td>2.363</td></tr></table>  Graph 2: Modal Periods and Frequencies  Graph 3: Modal Frequencies Table 15: Compared of column axial forces in soft soil of structures II, III, IV, V with structure I <table><tr><td colspan="5">Column axial forces "P"</td><td>Struct II</td><td>Struct III</td><td>Struct IV</td><td>Struct V</td></tr><tr><td>"Story"</td><td>"Column"</td><td>"Unique - Name"</td><td>"Load Case- Combo"</td><td>"Station"m</td><td>"P"</td><td>"P"</td><td>"P"</td><td>"P"</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQXP)</td><td>0,1.45,2.9</td><td>0%</td><td>2%</td><td>1%</td><td>1%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQYP)</td><td>0,1.45,2.9</td><td>-2%</td><td>-1%</td><td>-1%</td><td>-1%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQXP)</td><td>0,1.45,2.9</td><td>1%</td><td>2%</td><td>1%</td><td>1%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQYP)</td><td>0,1.45,2.9</td><td>-2%</td><td>-1%</td><td>-1%</td><td>-1%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQXP</td><td>0,1.45,2.9</td><td>8%</td><td>19%</td><td>11%</td><td>9%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQYP</td><td>0,1.45,2.9</td><td>-21%</td><td>-11%</td><td>-17%</td><td>-15%</td></tr><tr><td>"Story"</td><td>"Column"</td><td>"Unique-Name"</td><td>"Load Case-Combo"</td><td>"Station"m</td><td>"P"</td><td>"P"</td><td>"P"</td><td>"P"</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQXP)</td><td>0,1.45,2.9</td><td>1%</td><td>2%</td><td>2%</td><td>1%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQYP)</td><td>0,1.45,2.9</td><td>-2%</td><td>-1%</td><td>-1%</td><td>-1%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQXP)</td><td>0,1.45,2.9</td><td>1%</td><td>3%</td><td>2%</td><td>1%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQYP)</td><td>0,1.45,2.9</td><td>-2%</td><td>-1%</td><td>-1%</td><td>-1%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQXP</td><td>0,1.45,2.9</td><td>8%</td><td>19%</td><td>16%</td><td>9%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQYP</td><td>0,1.45,2.9</td><td>-21%</td><td>-11%</td><td>-10%</td><td>-15%</td></tr></table> Table 17: Compared of column axial forces in hard soil of structures II, III, IV, V with structure I <table><tr><td colspan="5">Column axial forces "P"</td><td>Struct II</td><td>Struct III</td><td>Struct IV</td><td>Struct V</td></tr><tr><td>"Story"</td><td>"Column"</td><td>"Unique - Name"</td><td>"Load Case-Combo"</td><td>"Station"m</td><td>"P"</td><td>"P"</td><td>"P"</td><td>"P"</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQXP)</td><td>0,1.45,2.9</td><td>1%</td><td>3%</td><td>2%</td><td>1%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQYP)</td><td>0,1.45,2.9</td><td>-2%</td><td>-1%</td><td>-1%</td><td>-1%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQXP)</td><td>0,1.45,2.9</td><td>1%</td><td>4%</td><td>3%</td><td>2%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQYP)</td><td>0,1.45,2.9</td><td>-3%</td><td>-1%</td><td>-1%</td><td>-2%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQXP</td><td>0,1.45,2.9</td><td>8%</td><td>19%</td><td>16%</td><td>9%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQYP</td><td>0,1.45,2.9</td><td>-21%</td><td>-11%</td><td>-10%</td><td>-15%</td></tr></table> Table 18: Compared of column moment in soft soil of structures II, III, IV, V with structure I <table><tr><td colspan="5">Column moment forces "M"</td><td>Struct II</td><td>Struct III</td><td>Struct IV</td><td>Struct V</td></tr><tr><td>"Story"</td><td>"Column"</td><td>"Unique - Name"</td><td>"Load Case-Combo"</td><td>"Station"m</td><td>"M"</td><td>"M"</td><td>"M"</td><td>"M"</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQXP)</td><td>0,1.45,2.9</td><td>564%</td><td>4%</td><td>-5%</td><td>4%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQYP)</td><td>0,1.45,2.9</td><td>-54%</td><td>-35%</td><td>-42%</td><td>-46%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQXP)</td><td>0,1.45,2.9</td><td>-54%</td><td>4%</td><td>-1%</td><td>4%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQYP)</td><td>0,1.45,2.9</td><td>-62%</td><td>-39%</td><td>-47%</td><td>-47%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQXP</td><td>0,1.45,2.9</td><td>0%</td><td>45%</td><td>41%</td><td>44%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQYP</td><td>0,1.45,2.9</td><td>0%</td><td>13%</td><td>8%</td><td>5%</td></tr></table> Table 19: Compared of column moment in medium soil of structures II, III, IV, V with structure I <table><tr><td colspan="5">Column moment forces "M"</td><td>Struct II</td><td>Struct III</td><td>Struct IV</td><td>Struct V</td></tr><tr><td>"Story"</td><td>"Column"</td><td>"Unique - Name"</td><td>"Load Case-Combo"</td><td>"Station"m</td><td>"M"</td><td>"M"</td><td>"M"</td><td>"M"</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQXP)</td><td>0,1.45,2.9</td><td>-187%</td><td>5%</td><td>5%</td><td>5%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQYP)</td><td>0,1.45,2.9</td><td>-55%</td><td>-35%</td><td>-34%</td><td>-46%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQXP)</td><td>0,1.45,2.9</td><td>-55%</td><td>5%</td><td>5%</td><td>4%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQYP)</td><td>0,1.45,2.9</td><td>-62%</td><td>-39%</td><td>-38%</td><td>-47%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQXP</td><td>0,1.45,2.9</td><td>0%</td><td>45%</td><td>45%</td><td>44%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQYP</td><td>0,1.45,2.9</td><td>0%</td><td>13%</td><td>13%</td><td>5%</td></tr><tr><td>"Story"</td><td>"Column"</td><td>"Unique - Name"</td><td>"Load Case-Combo"</td><td>"Station"m</td><td>"M"</td><td>"M"</td><td>"M"</td><td>"M"</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQXP)</td><td>0,1.45,2.9</td><td>-127%</td><td>6%</td><td>5%</td><td>5%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQYP)</td><td>0,1.45,2.9</td><td>-55%</td><td>-35%</td><td>-34%</td><td>-46%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQXP)</td><td>0,1.45,2.9</td><td>-55%</td><td>6%</td><td>6%</td><td>5%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQYP)</td><td>0,1.45,2.9</td><td>-62%</td><td>-39%</td><td>-38%</td><td>-47%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQXP</td><td>0,1.45,2.9</td><td>0%</td><td>45%</td><td>45%</td><td>44%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQYP</td><td>0,1.45,2.9</td><td>0%</td><td>13%</td><td>13%</td><td>5%</td></tr></table> Table 21: Compared of column shear in soft soil of structures II, III, IV, V with structure I <table><tr><td colspan="5">Column shear forces "V"</td><td>Struct II</td><td>Struct III</td><td>Struct IV</td><td>Struct V</td></tr><tr><td>"Story"</td><td>"Column"</td><td>"Unique - Name"</td><td>"Load Case-Combo"</td><td>"Station"m</td><td>"V"</td><td>"V"</td><td>"V"</td><td>"V"</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQXP)</td><td>0,1,45,2.9</td><td>-17%</td><td>14%</td><td>1%</td><td>-20%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQYP)</td><td>0,1,45,2.9</td><td>215%</td><td>175%</td><td>191%</td><td>-599%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQXP)</td><td>0,1,45,2.9</td><td>-12%</td><td>20%</td><td>8%</td><td>-18%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQYP)</td><td>0,1,45,2.9</td><td>166%</td><td>148%</td><td>155%</td><td>955%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQXP</td><td>0,1,45,2.9</td><td>13%</td><td>41%</td><td>30%</td><td>-5%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQYP</td><td>0,1,45,2.9</td><td>83%</td><td>86%</td><td>85%</td><td>64%</td></tr></table> Table 22: Compared of column shear in medium soil of structures II, III, IV, V with structure I <table><tr><td colspan="5">Column shear forces "V"</td><td>Struct II</td><td>Struct III</td><td>Struct IV</td><td>Struct V</td></tr><tr><td>"Story"</td><td>"Column"</td><td>"Unique - Name"</td><td>"Load Case-Combo"</td><td>"Station"m</td><td>"V"</td><td>"V"</td><td>"V"</td><td>"V"</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQXP)</td><td>0,1,45,2.9</td><td>-10%</td><td>21%</td><td>14%</td><td>-17%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQYP)</td><td>0,1,45,2.9</td><td>173%</td><td>152%</td><td>157%</td><td>2154%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQXP)</td><td>0,1,45,2.9</td><td>-5%</td><td>26%</td><td>18%</td><td>-15%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQYP)</td><td>0,1,45,2.9</td><td>142%</td><td>132%</td><td>134%</td><td>325%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQXP</td><td>0,1,45,2.9</td><td>13%</td><td>41%</td><td>34%</td><td>-5%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQYP</td><td>0,1,45,2.9</td><td>83%</td><td>86%</td><td>86%</td><td>64%</td></tr></table> Table 23: Compared of column shear in hard soil of structures II, III, IV, V with structure I <table><tr><td colspan="5">Column shear forces "V"</td><td>Struct II</td><td>Struct III</td><td>Struct IV</td><td>Struct V</td></tr><tr><td>"Story"</td><td>"Column"</td><td>"Unique - Name"</td><td>"Load Case-Combo"</td><td>"Station"m</td><td>"V"</td><td>"V"</td><td>"V"</td><td>"V"</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQXP)</td><td>0,1.45,2.9</td><td>-6%</td><td>25%</td><td>18%</td><td>-15%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQYP)</td><td>0,1.45,2.9</td><td>154%</td><td>140%</td><td>143%</td><td>521%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQXP)</td><td>0,1.45,2.9</td><td>-2%</td><td>29%</td><td>21%</td><td>-13%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQYP)</td><td>0,1.45,2.9</td><td>131%</td><td>124%</td><td>125%</td><td>226%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQXP</td><td>0,1.45,2.9</td><td>13%</td><td>41%</td><td>34%</td><td>-5%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQYP</td><td>0,1.45,2.9</td><td>83%</td><td>86%</td><td>86%</td><td>64%</td></tr></table> Table 24: Compared of column torsion in soft soil of structures II, III, IV, V with structure I <table><tr><td colspan="5">Column torsion forces "T"</td><td>Struct II</td><td>Struct III</td><td>Struct IV</td><td>Struct V</td></tr><tr><td>"Story"</td><td>"Column"</td><td>"Unique-Name"</td><td>"Load Case-Combo"</td><td>"Station"m</td><td>"T"</td><td>"T"</td><td>"T"</td><td>"T"</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQXP)</td><td>0,1.45,2.9</td><td>-42%</td><td>7%</td><td>2%</td><td>5%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQYP)</td><td>0,1.45,2.9</td><td>-42%</td><td>7%</td><td>2%</td><td>7%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQXP)</td><td>0,1.45,2.9</td><td>-42%</td><td>7%</td><td>2%</td><td>5%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQYP)</td><td>0,1.45,2.9</td><td>-42%</td><td>7%</td><td>2%</td><td>7%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQXP</td><td>0,1.45,2.9</td><td>-42%</td><td>7%</td><td>1%</td><td>5%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQYP</td><td>0,1.45,2.9</td><td>-41%</td><td>8%</td><td>2%</td><td>7%</td></tr></table> Table 25: Compared of column torsion in medium soil of structures II, III, IV, V with structure I <table><tr><td colspan="5">Column torsion forces "T"</td><td>Struct II</td><td>Struct III</td><td>Struct IV</td><td>Struct V</td></tr><tr><td>"Story"</td><td>"Column"</td><td>"Unique - Name"</td><td>"Load Case-Combo"</td><td>"Station"m</td><td>"T"</td><td>"T"</td><td>"T"</td><td>"T"</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQXP)</td><td>0,1.45,2.9</td><td>-42%</td><td>7%</td><td>7%</td><td>5%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQYP)</td><td>0,1.45,2.9</td><td>-42%</td><td>7%</td><td>8%</td><td>7%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQXP)</td><td>0,1.45,2.9</td><td>-42%</td><td>7%</td><td>7%</td><td>5%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQYP)</td><td>0,1.45,2.9</td><td>-42%</td><td>7%</td><td>8%</td><td>7%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQXP</td><td>0,1.45,2.9</td><td>-42%</td><td>7%</td><td>7%</td><td>5%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQYP</td><td>0,1.45,2.9</td><td>-41%</td><td>8%</td><td>8%</td><td>7%</td></tr></table> Table 26: Compared of column torsion in hard soil of structures II, III, IV, V with structure I <table><tr><td colspan="5">Column torsion forces "T"</td><td>Struct II</td><td>Struct III</td><td>Struct IV</td><td>Struct V</td></tr><tr><td>"Story"</td><td>"Column"</td><td>"Unique - Name"</td><td>"Load Case-Combo"</td><td>"Station"m</td><td>"T"</td><td>"T"</td><td>"T"</td><td>"T"</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQXP)</td><td>0,1.45,2.9</td><td>-42%</td><td>7%</td><td>7%</td><td>5%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQYP)</td><td>0,1.45,2.9</td><td>-42%</td><td>7%</td><td>8%</td><td>7%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQXP)</td><td>0,1.45,2.9</td><td>-42%</td><td>7%</td><td>7%</td><td>5%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQYP)</td><td>0,1.45,2.9</td><td>-42%</td><td>7%</td><td>8%</td><td>7%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQXP</td><td>0,1.45,2.9</td><td>-42%</td><td>7%</td><td>7%</td><td>5%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQYP</td><td>0,1.45,2.9</td><td>-41%</td><td>8%</td><td>8%</td><td>7%</td></tr></table> Table 27: Compared of column axial forces of medium soil and hard soil with soft soil for Structure -I <table><tr><td colspan="5">Column Axial Forces "P"</td><td>"Medium soil"</td><td>"Hard soil"</td></tr><tr><td>"Story"</td><td>"Column"</td><td>"Unique- Name"</td><td>"Load Case-Combo"</td><td>"Station"m</td><td>"P"</td><td>"P"</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQXP)</td><td>0,1.45,2.9</td><td>3%</td><td>6%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQYP)</td><td>0,1.45,2.9</td><td>2%</td><td>4%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQXP)</td><td>0,1.45,2.9</td><td>4%</td><td>7%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQYP)</td><td>0,1.45,2.9</td><td>3%</td><td>5%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQXP</td><td>0,1.45,2.9</td><td>26%</td><td>40%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQYP</td><td>0,1.45,2.9</td><td>26%</td><td>40%</td></tr></table> Table 28: Compared of column axial forces of medium soil and hard soil with soft soil for Structure -II <table><tr><td colspan="5">Column Axial Forces "P"</td><td>"Medium soil"</td><td>"Hard soil"</td></tr><tr><td>"Story"</td><td>"Column"</td><td>"Unique-Name"</td><td>"Load Case-Combo"</td><td>"Station"m</td><td>"P"</td><td>"P"</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQXP)</td><td>0,1.45,2.9</td><td>3%</td><td>6%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQYP)</td><td>0,1.45,2.9</td><td>2%</td><td>4%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQXP)</td><td>0,1.45,2.9</td><td>4%</td><td>7%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQYP)</td><td>0,1.45,2.9</td><td>2%</td><td>4%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQXP</td><td>0,1.45,2.9</td><td>26%</td><td>40%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQYP</td><td>0,1.45,2.9</td><td>26%</td><td>40%</td></tr></table> Table 29: Compared of column axial forces of medium soil and hard soil with soft soil for Structure -III <table><tr><td colspan="5">Column Axial Forces "P"</td><td>"Medium soil"</td><td>"Hard soil"</td></tr><tr><td>"Story"</td><td>"Column"</td><td>"Unique-Name"</td><td>"Load Case-Combo"</td><td>"Station"m</td><td>"P"</td><td>"P"</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQXP)</td><td>0,1.45,2.9</td><td>4%</td><td>7%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQYP)</td><td>0,1.45,2.9</td><td>2%</td><td>4%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQXP)</td><td>0,1.45,2.9</td><td>4%</td><td>8%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQYP)</td><td>0,1.45,2.9</td><td>3%</td><td>5%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQXP</td><td>0,1.45,2.9</td><td>26%</td><td>40%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQYP</td><td>0,1.45,2.9</td><td>26%</td><td>40%</td></tr></table> Table 30: Compared of column axial forces of medium soil and hard soil with soft soil for Structure -IV <table><tr><td colspan="5">Column Axial Forces "P"</td><td>"Medium soil"</td><td>"Hard soil"</td></tr><tr><td>"Story"</td><td>"Column"</td><td>"Unique- Name"</td><td>"Load Case-Combo"</td><td>"Station"m</td><td>"P"</td><td>"P"</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQXP)</td><td>0,1.45,2.9</td><td>4%</td><td>7%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQYP)</td><td>0,1.45,2.9</td><td>3%</td><td>4%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQXP)</td><td>0,1.45,2.9</td><td>5%</td><td>8%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQYP)</td><td>0,1.45,2.9</td><td>3%</td><td>5%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQXP</td><td>0,1.45,2.9</td><td>31%</td><td>44%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQYP</td><td>0,1.45,2.9</td><td>31%</td><td>44%</td></tr></table> Table 31: Compared of column axial forces of medium soil and hard soil with soft soil for Structure -V <table><tr><td colspan="5">Column Axial Forces "P"</td><td>"Medium soil"</td><td>"Hard soil"</td></tr><tr><td>"Story"</td><td>"Column"</td><td>"Unique-Name"</td><td>"Load Case-Combo"</td><td>"Station"m</td><td>"P"</td><td>"P"</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQXP)</td><td>0,1.45,2.9</td><td>3%</td><td>6%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQYP)</td><td>0,1.45,2.9</td><td>2%</td><td>4%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQXP)</td><td>0,1.45,2.9</td><td>4%</td><td>7%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQYP)</td><td>0,1.45,2.9</td><td>3%</td><td>5%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQXP</td><td>0,1.45,2.9</td><td>26%</td><td>40%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQYP</td><td>0,1.45,2.9</td><td>26%</td><td>40%</td></tr></table> Table 32: Compared of column moment of medium soil and hard soil with soft soil for Structure -I <table><tr><td colspan="5">Column Moment Forces "M"</td><td>"Medium soil"</td><td>"Hard soil"</td></tr><tr><td>"Story"</td><td>"Column"</td><td>"Unique-Name"</td><td>"Load Case-Combo"</td><td>"Station"m</td><td>"M"</td><td>"M"</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQXP)</td><td>0,1.45,2.9</td><td>20%</td><td>32%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQYP)</td><td>0,1.45,2.9</td><td>-7%</td><td>-14%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQXP)</td><td>0,1.45,2.9</td><td>21%</td><td>34%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQYP)</td><td>0,1.45,2.9</td><td>-11%</td><td>-23%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQXP</td><td>0,1.45,2.9</td><td>26%</td><td>40%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQYP</td><td>0,1.45,2.9</td><td>26%</td><td>40%</td></tr></table> Table 33: Compared of column moment of medium soil and hard soil with soft soil for Structure -II <table><tr><td colspan="5">Column Moment Forces "M"</td><td>"Medium soil"</td><td>"Hard soil"</td></tr><tr><td>"Story"</td><td>"Column"</td><td>"Unique-Name"</td><td>"Load Case-Combo"</td><td>"Station"m</td><td>"M"</td><td>"M"</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQXP)</td><td>0,1.45,2.9</td><td>25%</td><td>38%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQYP)</td><td>0,1.45,2.9</td><td>32%</td><td>46%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQXP)</td><td>0,1.45,2.9</td><td>26%</td><td>39%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQYP)</td><td>0,1.45,2.9</td><td>29%</td><td>43%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQXP</td><td>0,1.45,2.9</td><td>26%</td><td>40%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQYP</td><td>0,1.45,2.9</td><td>26%</td><td>40%</td></tr></table> Table 34: Compared of column moment of medium soil and hard soil with soft soil for Structure -III <table><tr><td colspan="5">Column Moment Forces "M"</td><td>"Medium soil"</td><td>"Hard soil"</td></tr><tr><td>"Story"</td><td>"Column"</td><td>"Unique-Name"</td><td>"Load Case-Combo"</td><td>"Station"m</td><td>"M"</td><td>"M"</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQXP)</td><td>0,1.45,2.9</td><td>27%</td><td>40%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQYP)</td><td>0,1.45,2.9</td><td>26%</td><td>40%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQXP)</td><td>0,1.45,2.9</td><td>27%</td><td>41%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQYP)</td><td>0,1.45,2.9</td><td>25%</td><td>39%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQXP</td><td>0,1.45,2.9</td><td>26%</td><td>40%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQYP</td><td>0,1.45,2.9</td><td>26%</td><td>40%</td></tr></table> Table 35: Compared of column moment of medium soil and hard soil with soft soil for Structure -IV <table><tr><td colspan="5">Column Moment Forces "M"</td><td>"Medium soil"</td><td>"Hard soil"</td></tr><tr><td>"Story"</td><td>"Column"</td><td>"Unique-Name"</td><td>"Load Case-Combo"</td><td>"Station"m</td><td>"M"</td><td>"M"</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQXP)</td><td>0,1.45,2.9</td><td>30%</td><td>43%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQYP)</td><td>0,1.45,2.9</td><td>33%</td><td>46%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQXP)</td><td>0,1.45,2.9</td><td>31%</td><td>43%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQYP)</td><td>0,1.45,2.9</td><td>31%</td><td>44%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQXP</td><td>0,1.45,2.9</td><td>31%</td><td>44%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQYP</td><td>0,1.45,2.9</td><td>31%</td><td>44%</td></tr></table> Table 36: Compared of column moment of medium soil and hard soil with soft soil for Structure -V <table><tr><td colspan="5">Column Moment Forces "M"</td><td>"Medium soil"</td><td>"Hard soil"</td></tr><tr><td>"Story"</td><td>"Column"</td><td>"Unique-Name"</td><td>"Load Case-Combo"</td><td>"Station"m</td><td>"M"</td><td>"M"</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQXP)</td><td>0,1.45,2.9</td><td>22%</td><td>35%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQYP)</td><td>0,1.45,2.9</td><td>415%</td><td>169%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQXP)</td><td>0,1.45,2.9</td><td>23%</td><td>36%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQYP)</td><td>0,1.45,2.9</td><td>71%</td><td>82%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQXP</td><td>0,1.45,2.9</td><td>26%</td><td>40%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQYP</td><td>0,1.45,2.9</td><td>26%</td><td>40%</td></tr></table> Table 37: Compared of column shear of medium soil and hard soil with soft soil for Structure -I <table><tr><td colspan="5">Column Shear Forces "V"</td><td>"Medium soil"</td><td>"Hard soil"</td></tr><tr><td>"Story"</td><td>"Column"</td><td>"Unique-Name"</td><td>"Load Case-Combo"</td><td>"Station"m</td><td>"V"</td><td>"V"</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQXP)</td><td>0,1.45,2.9</td><td>30%</td><td>44%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQYP)</td><td>0,1.45,2.9</td><td>26%</td><td>40%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQXP)</td><td>0,1.45,2.9</td><td>29%</td><td>42%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQYP)</td><td>0,1.45,2.9</td><td>26%</td><td>40%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQXP</td><td>0,1.45,2.9</td><td>26%</td><td>40%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQYP</td><td>0,1.45,2.9</td><td>26%</td><td>40%</td></tr></table> Table 38: Compared of column shear of medium soil and hard soil with soft soil for Structure -II <table><tr><td colspan="5">Column Shear Forces "V"</td><td>"Medium soil"</td><td>"Hard soil"</td></tr><tr><td>"Story"</td><td>"Column"</td><td>"Unique-Name"</td><td>"Load Case-Combo"</td><td>"Station"m</td><td>"V"</td><td>"V"</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQXP)</td><td>0,1.45,2.9</td><td>56%</td><td>61%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQYP)</td><td>0,1.45,2.9</td><td>26%</td><td>40%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQXP)</td><td>0,1.45,2.9</td><td>40%</td><td>52%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQYP)</td><td>0,1.45,2.9</td><td>26%</td><td>40%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQXP</td><td>0,1.45,2.9</td><td>26%</td><td>40%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQYP</td><td>0,1.45,2.9</td><td>26%</td><td>40%</td></tr></table> Table 39: Compared of column shear of medium soil and hard soil with soft soil for Structure -III <table><tr><td colspan="5">Column Shear Forces "V"</td><td>"Medium soil"</td><td>"Hard soil"</td></tr><tr><td>"Story"</td><td>"Column"</td><td>"Unique-Name"</td><td>"Load Case-Combo"</td><td>"Station"m</td><td>"V"</td><td>"V"</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQXP)</td><td>0,1.45,2.9</td><td>31%</td><td>45%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQYP)</td><td>0,1.45,2.9</td><td>26%</td><td>40%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQXP)</td><td>0,1.45,2.9</td><td>29%</td><td>43%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQYP)</td><td>0,1.45,2.9</td><td>26%</td><td>40%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQXP</td><td>0,1.45,2.9</td><td>26%</td><td>40%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQYP</td><td>0,1.45,2.9</td><td>26%</td><td>40%</td></tr></table> Table 40: Compared of column shear of medium soil and hard soil with soft soil for Structure -IV <table><tr><td colspan="5">Column Shear Forces "V"</td><td>"Medium soil"</td><td>"Hard soil"</td></tr><tr><td>"Story"</td><td>"Column"</td><td>"Unique-Name"</td><td>"Load Case-Combo"</td><td>"Station"m</td><td>"V"</td><td>"V"</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQXP)</td><td>0,1.45,2.9</td><td>36%</td><td>48%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQYP)</td><td>0,1.45,2.9</td><td>31%</td><td>43%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQXP)</td><td>0,1.45,2.9</td><td>34%</td><td>47%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQYP)</td><td>0,1.45,2.9</td><td>31%</td><td>43%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQXP</td><td>0,1.45,2.9</td><td>31%</td><td>44%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQYP</td><td>0,1.45,2.9</td><td>31%</td><td>44%</td></tr></table> Table 41: Compared of column shear of medium soil and hard soil with soft soil for Structure -V <table><tr><td colspan="5">Column Shear Forces "V"</td><td>"Medium soil"</td><td>"Hard soil"</td></tr><tr><td>"Story"</td><td>"Column"</td><td>"Unique-Name"</td><td>"Load Case-Combo"</td><td>"Station"m</td><td>"V"</td><td>"V"</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQXP)</td><td>0,1.45,2.9</td><td>30%</td><td>44%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQYP)</td><td>0,1.45,2.9</td><td>26%</td><td>40%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQXP)</td><td>0,1.45,2.9</td><td>29%</td><td>43%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQYP)</td><td>0,1.45,2.9</td><td>26%</td><td>40%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQXP</td><td>0,1.45,2.9</td><td>26%</td><td>40%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQYP</td><td>0,1.45,2.9</td><td>26%</td><td>40%</td></tr></table> Table 42: Compared of column torsion of medium soil and hard soil with soft soil for Structure -I <table><tr><td colspan="5">Column Torsion Forces "T"</td><td>"Medium soil"</td><td>"Hard soil"</td></tr><tr><td>"Story"</td><td>"Column"</td><td>"Unique-Name"</td><td>"Load Case-Combo"</td><td>"Station"m</td><td>"T"</td><td>"T"</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQXP)</td><td>0,1.45,2.9</td><td>0%</td><td>0%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQYP)</td><td>0,1.45,2.9</td><td>26%</td><td>40%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQXP)</td><td>0,1.45,2.9</td><td>26%</td><td>40%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQYP)</td><td>0,1.45,2.9</td><td>26%</td><td>40%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQXP</td><td>0,1.45,2.9</td><td>26%</td><td>40%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQYP</td><td>0,1.45,2.9</td><td>26%</td><td>40%</td></tr></table> Table 43: Compared of column torsion of medium soil and hard soil with soft soil for Structure -II <table><tr><td colspan="5">Column Torsion Forces "T"</td><td>"Medium soil"</td><td>"Hard soil"</td></tr><tr><td>"Story"</td><td>"Column"</td><td>"Unique-Name"</td><td>"Load Case-Combo"</td><td>"Station"m</td><td>"T"</td><td>"T"</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQXP)</td><td>0,1.45,2.9</td><td>26%</td><td>40%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQYP)</td><td>0,1.45,2.9</td><td>27%</td><td>40%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQXP)</td><td>0,1.45,2.9</td><td>26%</td><td>40%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQYP)</td><td>0,1.45,2.9</td><td>27%</td><td>40%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQXP</td><td>0,1.45,2.9</td><td>26%</td><td>40%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQYP</td><td>0,1.45,2.9</td><td>26%</td><td>40%</td></tr></table> Table 44: Compared of column torsion of medium soil and hard soil with soft soil for Structure -III <table><tr><td colspan="5">Column Torsion Forces "T"</td><td>"Medium soil"</td><td>"Hard soil"</td></tr><tr><td>"Story"</td><td>"Column"</td><td>"Unique-Name"</td><td>"Load Case-Combo"</td><td>"Station"m</td><td>"T"</td><td>"T"</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQXP)</td><td>0,1.45,2.9</td><td>26%</td><td>40%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQYP)</td><td>0,1.45,2.9</td><td>27%</td><td>40%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQXP)</td><td>0,1.45,2.9</td><td>26%</td><td>40%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQYP)</td><td>0,1.45,2.9</td><td>27%</td><td>40%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQXP</td><td>0,1.45,2.9</td><td>26%</td><td>40%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQYP</td><td>0,1.45,2.9</td><td>26%</td><td>40%</td></tr></table> Table 45: Compared of column torsion of medium soil and hard soil with soft soil for Structure -IV <table><tr><td colspan="5">Column Torsion Forces "T"</td><td>"Medium soil"</td><td>"Hard soil"</td></tr><tr><td>"Story"</td><td>"Column"</td><td>"Unique-Name"</td><td>"Load Case-Combo"</td><td>"Station"m</td><td>"T"</td><td>"T"</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQXP)</td><td>0,1.45,2.9</td><td>31%</td><td>44%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQYP)</td><td>0,1.45,2.9</td><td>31%</td><td>44%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQXP)</td><td>0,1.45,2.9</td><td>31%</td><td>44%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQYP)</td><td>0,1.45,2.9</td><td>31%</td><td>44%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQXP</td><td>0,1.45,2.9</td><td>31%</td><td>44%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQYP</td><td>0,1.45,2.9</td><td>31%</td><td>44%</td></tr></table> Table 46: Compared of column torsion of medium soil and hard soil with soft soil for Structure -V <table><tr><td colspan="5">Column Torsion Forces "T"</td><td>"Medium soil"</td><td>"Hard soil"</td></tr><tr><td>"Story"</td><td>"Column"</td><td>"Unique-Name"</td><td>"Load Case-Combo"</td><td>"Station"m</td><td>"T"</td><td>"T"</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQXP)</td><td>0,1.45,2.9</td><td>26%</td><td>40%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.2(DL+LL+EQYP)</td><td>0,1.45,2.9</td><td>27%</td><td>40%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQXP)</td><td>0,1.45,2.9</td><td>26%</td><td>40%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>1.5(DL+EQYP)</td><td>0,1.45,2.9</td><td>27%</td><td>40%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQXP</td><td>0,1.45,2.9</td><td>26%</td><td>40%</td></tr><tr><td>1ST</td><td>C34</td><td>67</td><td>EQYP</td><td>0,1.45,2.9</td><td>26%</td><td>40%</td></tr></table> ### a) Discussion on Results When a structure is subjected to earthquake, it responds by vibrating. An example force can be resolved into three mutually perpendicular directions: two horizontal directions (X and Y directions) and the vertical direction (Z) [8]. This motion causes the structure to vibrate or shake in all three directions; the predominant direction of shaking is horizontal. All the structures are primarily designed for gravity loads-force equal to mass time's gravity in the vertical direction. Vertical acceleration should also be considered in structures with large spans those in which stability for design, or for overall stability analysis of structures. The basic intent of design theory for earthquake resistant structures is that buildings should be able to resist minor earthquakes without damage, resist moderate earthquakes without structural damage but with some non-structural damage. To avoid collapse during a major earthquake, Members must be ductile enough to absorb and dissipate energy by post elastic deformation. Redundancy in the structural system permits redistribution of internal forces in the event of the failure of key elements. When the primary element or system yields or fails, the lateral force can be redistributed to a secondary system to prevent progressive failure. When a structure is subjected to an earthquake excitation, it interacts with the foundation and the soil, and thus changes the motion of the ground[2,8]. This means that the movement of the whole ground-structure system is influenced by the type of soil as well as by the type of structure. Understanding of soil structure interaction will enable the designer to design structures that will behave better during an earthquake. ## V. CONCLUSIONS From the above results and discussions, following conclusions can be drawn: - The shear wall and it is position has a significant influenced on the time period, the time period is not influenced by the type of soil, in tall building with box shape Shear Walls is showing the low time period which shows a very significant performance. - Shear is effected marginally by placing of the shear wall, grouping of shear wall and type of soil. The shear is increased by adding shear wall due to increase the seismic weight of the building. - The Axial force and Moment in the column increases when the type of soil changes from hard to medium and medium to soft. Since the column moment increase as the soil type changes, soil structure interaction must be suitably considered while designing frames for seismic force. - It is evident that the maximum column axial force is various with type of soil and placing of the shear wall. - It is evident that the maximum column shear force in X-direction is influenced by the type of soil and placing of the shear wall. - It is evident that the maximum column shear force in Y-direction has no influence on the type of soil and placing shear wall. - It is evident that the maximum column torsion is same for all columns in a structure, but is influenced by the type of soil and placing shear wall. - It is evident that the maximum column moment in X-direction has no influence on the type of soil and placing shear wall. - It is evident that the maximum column moment in Y-direction is influenced by the type of soil and placing of shear wall. - It is evident that the results from 1.2 (DL + IL ± EL) combination load is closed to the 1.5 (DL + EL) and there is no more difference between these combination load. - Based on the analysis and discussion, shear wall are very much suitable for resisting earthquake induced lateral forces in multistoried structural systems when compared to multistoried structural systems whit out shear walls. They can be made to behave in a ductile manner by adopting proper detailing techniques. - According to IS-1893:2002 the number of modes to be used in the analysis should be such that the total sum of modal masses of all modes considered is at least 90 percent of the total seismic mass. Here the maximum mass is for the tall building with box shape RC shear wall. - ETABS is the robust software which is utilized for analyzing any kind of multi building structures. ## ACKNOWLEDGMENTS Conflict of Interest The author declare no conflict of interest. Data Availability Statement All data generated or analysed during this study are included in this article.
