New Formulas for the Mutual Inductance and the Magnetic Force of the System: Thin Disk Coil (Pancake) with Inverse Radial Current Density and Thin Wall Solenoid with Constant Azimuthal Current Density

Slobodan Babic; Cevdet Akyel

New Formulas for the Mutual Inductance and the Magnetic Force of the System: Thin Disk Coil (Pancake) with Inverse Radial Current Density and Thin Wall Solenoid with Constant Azimuthal Current Density

Slobodan Babic *

Contact

Cevdet Akyel

Contact

New Formulas for the Mutual Inductance and the Magnetic Force of the System: Thin Disk Coil (Pancake) with Inverse Radial Current Density and Thin Wall Solenoid with Constant Azimuthal Current Density

Article Fingerprint

ReserarchID

RE0Y4YI

AI TAKEAWAY

Connecting with the Eternal Ground

Abstract

This paper deals with two coaxial circular coils (thin disk coil and thin wall solenoid) for which we calculated the electromagnetic quantities such as the mutual inductance and the magnetic force. The disk coil (pancake) is with the nonlinear inverse radial current and the wall solenoid with the constant current in the azimuthal direction. The circular coils with the nonlinear inverse radial current are well known as the Bitter coils, and the circular coils with the azimuthal current are well known as the ordinary coils. Also, the coils with the azimuthal current can serve as the superconducting coils. These calculations give the semi-analytical and the analytical expressions respectively for these electromagnetic quantities. Also, we presented the improved filament method as the comparative method.
